IP55 PET Bottle Blowing DN65 Variable Speed Rotary Screw Air Compressor Unit
IP55 PET Bottle Blowing DN65 Variable Speed Rotary Screw Air Compressor Unit
IP55 PET Bottle Blowing DN65 Variable Speed Rotary Screw Air Compressor Unit
IP55 PET Bottle Blowing DN65 Variable Speed Rotary Screw Air Compressor Unit
Specifications
Brand Name :
GooDSeaA
Model Number :
SE250A-25
Certification :
ISO,CE
Place of Origin :
Shanghai, China
MOQ :
1pc
Price :
USD88500/PC-USD92500/PCS
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50pcs/month
Delivery Time :
35days -45days
Packaging Details :
standard export carton box
Name :
25bar Middle/High Pressure Air Compressor
Type :
Middle Pressure
Compression Stage :
Two Stage
Power :
250kw
Pressure :
25bar
Air Flow :
22.0m3/min
Cooling Method :
Air Cooled
Material :
Cast Iron
Description

250kw 25bar Medium Pressure Air Compressor for PET Bottle Blowing

High pressure screw air compressors serve a wide range of purposes in industrial, manufacturing and other applications. GooDSeaA has been manufacturing both low and high pressure machines since 2004.

What is Pressure?

Pressure is the amount of force produced by an air compressor, relative to the surrounding atmosphere. For most commercial or industrial applications, it is measured in pounds per square inch gauge (PSIG). You may also see it rated in bar, or bar(g), the metric equivalent of PSIG.

Any machine delivering more than 150 PSIG is generally considered to be a high pressure compressor. Most handheld tools are rated at 90 PSIG, meaning a standard pressure machine can easily power them.

High Pressure Compressor Applications

High pressure screw compressors have a number of very specific uses, particularly in industrial and energy applications. You can find them on offshore drilling rigs and remote pipeline settings, where they are used to start engines and motors, or to help convey drilling mud. They are also used to drive turbines and generators in power plants, and for various processes in manufacturing facilities.

Technical Data

High Pressure Screw Air Compressor

Model

SE250A-25

Note

Free air delivery (m3/min)

22.0

776.6cfm

Max working pressure (bar)

25

2.5Mpa

Power (kW)

250

340hp

Voltage (V/P/Hz)

380V/3P/50Hz

Voltage can be customized

Noise level dB(A)

82

Cooling method

Air cooling

water cooling is optional

Drive method

Coupling

Motor protection

IP55,F

Suction air temperature (℃)

≦50

Outlet temperature (℃)

Ambient Tem. + 8~10℃

Compressed air control method

Automatic(0-100%)

Control method

PLC Intelligent

English

Oil content

1~3ppm

Connection (mm)

DN 65

Dimensions (L×W×H) mm

3250*2250*2050

Weight (Kg)

4500

Configuration

IP55 PET Bottle Blowing DN65 Variable Speed Rotary Screw Air Compressor Unit

More Models

MODEL POWER

AIR FLOW

m3/min

PRESSSURE

bar

OUTLET

CONNECTION

WEIGHT

kg

DIMENSION

L*W*H mm
kw hp

SE90W-20

SE90W-25

 90 120

9.2

8.5

20

25

 DN 40 2750 2466*1900*1918

SE110W-20

SE110W-25

 110 150

11.6

9.7

20

25

 DN 40 2900 2466*1900*1918

SE132W-20

SE132W-25

SE132W-30

 132 180

13.0

11.8

10.5

20

25

30

 DN 50 3200 2466*1900*1918
SE160W-20 160 220 15.5 25 DN 50 3850 2850*1950*1950

SE200W-20

SE200W-25

 200 270

21.0

18.8

20

25

 DN 65 4200 2980*2100*1950

SE250W-20

SE250W-25

 250 340

25.0

22.0

20

25

 DN 65 4500 3250*2250*2050

Note: the above listed are of our standard models. For different needs, the special design service is available. Welcome to pre-sales technical consultation at any time.
