Specifications
Brand Name :
Turboo
Model Number :
ES3216
Certification :
CE ISO9001
Place of Origin :
Guangdong China (Mainland)
MOQ :
2 pcs
Price :
Bargain
Payment Terms :
L/C, T/T
Supply Ability :
1000 units per month
Delivery Time :
7 days
Packaging Details :
Wooden Case Package
Size（L*W*H) :
1400*160*980mm
Fuselage material :
Top cover 1.2mm+body 0.9mm 304 brushed plate
Diaphragm material :
8mm clear acrylic
Pass width :
600-900mm
Movement :
Brushless swing brake integrated movement
Power supply :
24V 150W
Sensor pairs :
6 pairs
Environment :
Indoor and outdoor (outdoor with canopy)
Description

Integrated Design Turnstiles Stainless Steel Swing Gate for Office Security Gate

Parameter of ES3216 swing gate

Size(L*W*H) 1400*160*980mm
Fuselage material Top cover 1.2mm+body 0.9mm 304 brushed plate
Diaphragm material

8mm clear acrylic
Baffle material 10mm clear acrylic
Pass width 600-900mm
Baffle interception height 820mm
Height of baffle from ground 200mm
Movement Brushless swing brake integrated movement
Power supply 24V 150W
Input voltage AC100V~240V,50/60HZ
Drive motor Fengdun DC brushless 90K 30W
Pass rate

Open 50 people/min; Usually closed 35 people/min
Speed of opening and closing Adjustable from 0.5s to 1.5s
Sensor pairs 6 pairs
Pilot lamp Three color light panel+three color light strip
Controls 1V2 brushless simplified board+electric control box+mesh board box
Noise ≤65dB
Temperature -20℃~+70℃
Humidity ≤90% No condensation
Class of protection IP4X
Environment Indoor and outdoor (outdoor with canopy)

Integrated Design Swing Turnstiles Gate Stainless Steel Office Security Gates

​

Advantages of ES3216 swing gate
1) the most cost-effective turnstile gate
Why is the price so good?
Molded Design Greatly reduces the welding and easy for mass-production.
No Profit We hope to further increase our sales by this top-sales product.
2) a turnstile gate that can be installed both indoor and outdoor
IP rating is IP45!
Full Welding Top cover is full welding, can prevent dust and liquids from ingressing from the outside.
Waterproof Box Controller, power supply etc are euipped with waterproof box to prevent dust and liquids.
3) a turnstile gate that passes both people and vehicles
Pass Width Pass width can be from 600mm to 1100mm, bicycles and motors can pass safely and orderly.
Two Kind of Baffles Acrylic and stainless stieel are optional.
4) a high security and safety turnstile gate
Six pairs of infrared sensors Can detect within 100mm.
Current Anti-pinch Function It will automatically rebounf after hitting a person when closing, double ensure anti-pinch.

On-site case pictures of ES3216 swing gate

Integrated Design Swing Turnstiles Gate Stainless Steel Office Security Gates Integrated Design Swing Turnstiles Gate Stainless Steel Office Security Gates
Integrated Design Swing Turnstiles Gate Stainless Steel Office Security Gates Integrated Design Swing Turnstiles Gate Stainless Steel Office Security Gates
