Horizontal Lathe Milling Machine , Large Manual Spinning Lathe Machine
Horizontal Lathe Milling Machine , Large Manual Spinning Lathe Machine
Horizontal Lathe Milling Machine , Large Manual Spinning Lathe Machine
Horizontal Lathe Milling Machine , Large Manual Spinning Lathe Machine
Horizontal Lathe Milling Machine , Large Manual Spinning Lathe Machine
Horizontal Lathe Milling Machine , Large Manual Spinning Lathe Machine
Specifications
Brand Name :
Baishun
Model Number :
CW61110Q
Certification :
ISO9001; CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 set/month
Delivery Time :
In stock
Packaging Details :
Export standard package for Horizontal Lathe machine
Product name :
Horizontal Lathe machine
Swing over bed :
1110mm
Spindle bore :
130mm
Machine function :
machining steel, casting, nonferrous metals and etc
Key word :
lathe machine
Color :
As customer's requirement
Warranty :
12month
CNC or Not :
Normal
Description

CW series CW6163 CW6263 CW6180/CW6280/CW61100/CW61125/CW61140 Heavy duty large Horizontal Lathe machine

Product Application

The horizontal lathe machine is mainly suitable for cutting the workpiece inside and outside round cylindrical, cone and other rotating parts, machinable various commonly used metric, inch, module and diametral pitch thread, and broaching oil groove and keyway.The machine has the following features:

1. The lathe bed by integrally cast lathe bed structure, internal steel board layout is reasonable, has high rigidity, machine adopts the 250 casting iron, equipment with high frequency quenching, guide rail mill grinding process, stable machine tools with high precision, high rigidity, strong cutting.

2. Sliding box has a fast moving structure, single handle visualization operation;Spindle and reversing shift to the brake and the user can choose the hydraulic control or manual control machinery.

3. The machine tool rest with single motor turning cylinder, you can also use the tool rest and longitudinal feed turning cone length.The machine it is suitable for large and medium-sized of steel and non-ferrous metal parts processing, can be cylindrical turning, inner hole, face cutting, drilling, boring and nesting.

4. The machine tool power, strong rigidity, spindle speed range is wide, suitable for strong or high speed cutting.Of spindle brake and shift to the hydraulic control, sensitive and reliable braking available button without a stop conversion speed, the forced lubrication with pressure oil in the cabinet of the head of a bed, spindle speed range has several kinds, for user to choose from.

5. Has security structure in the sliding box, which can prevent damage of lathe due to overload.

Design feature:

1. The combination of flat bed creates a structure of extremely high accuracy and rigidity.
2. Our flat bed CNC lathe is equipped with turrets of either Chinese or western origin, with high

rigidity and accuracy, and fast indexing speed.
3. Spindle utilizes double-row cylindrical roller bearings for high accuracy and rigidity.
4. Hydraulic tailstock is an available option

Lathe Milling Machine CW61110Q Specification:

Item

Unit

CW61110Q

Bed way type

Floor bed

Swing over bed

mm

1110

Swing over toolpost

mm

800

Center distance

mm

3000/5000/6000-15000

Spindle bore

mm

105

Front sindle bore and taper

mm

120 ,40 MT6

Spindle speed and step

r/min

18 kinds 8.5-720

Cross feed range and kinds

mm/r

64kinds 0.05-24.3

Range 1:1

mm/r

0.1-1.52

Range 16:1

mm/r

1.6-24.3

Change gear micro feed range

mm/r

0.05-0.76

propotion longitudinal feed to cross

1:2

Saddle rapid movement

mm/min

4000

Leadscrew pitch

mm

12(metric)1/2"(inch)

Metric thread range and kinds

mm

50 kinds 1-240

Inch thread range and kinds

26 kinds 14-1 t.p.i

Module thread range and kinds

mm

53 kinds 0.5-120

Pitch thread range and kinds

24 kinds 28-1 DP

Under turret max longitudinal travel

mm

315

Upper turret max travel

mm

200

Tailstock sleeve travel

mm

250

Tailstock sleeve taper

MT6

Main motor power

kW

11

Rapid motor power

kW

1.1

Coolant pump power

w

90

Bed width

mm

600

Guideway hardness

600RC52

Max load

kg

2500

Horizontal Lathe Milling Machine , Large Manual Spinning Lathe MachineHorizontal Lathe Milling Machine , Large Manual Spinning Lathe MachineHorizontal Lathe Milling Machine , Large Manual Spinning Lathe Machine

Horizontal Lathe Milling Machine , Large Manual Spinning Lathe Machine

Our Services


1. We will provide all the machines for the complete production according to customer's requirements.

2. We will provide complete service for factory layout and other information to help buyer.

3. We will provide good service for the machine installation and training, until the customers can operate the machine and make stable production.

4. Except one year quality guarantee, we will provide after-selling service for all the life.

5. For long-term cooperation, we always provide good quality, good price and good service to customer.
