Specifications
Brand Name :
BAI SHUN
Model Number :
BS-40
Certification :
ISO; CCC; CE
Place of Origin :
Henan; China(Mainland)
MOQ :
1set
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60set/Month
Delivery Time :
20 workingdays after received down payment
Packaging Details :
Export standard wooden box for fog cannon machine
Key words :
fog cannon sprayer machine
Sprayer Type :
Pump
Product name :
fog cannon machine
Metal Type :
Steel
Color :
As customerized
Usage :
Agriculture, garden, construction site and so on
Voltage :
220v/380/415v
Max Range :
40m
Fan power :
5.5Kw
Water pump power :
2.2Kw
Fog size :
30-200μm
Flow :
40-60L/Min
Horizontal rotation angle :
0-360°
control model :
electric control or touch screen
Description

Hot sale dust suppression spray machine fog cannon price for sale


Product Discription

The dust suppression fog cannon water spray machine first uses the imported high-pressure pump and the micro atomizing nozzle to atomize the water, and then uses the air volume and wind pressure of the fan to send the atomized water mist to a long distance, so that the water mist reaches a long distance. At the same time, it can cover a larger area, and the water mist and the dust condense and fall, thereby achieving the purpose of dust reduction.

The fog sprayer machine consists of water tank, water pipe, plunger pump, nozzle, fan, generator set (gasoline or diesel), horizontal steering device, vertical pitch device, electric control box, remote control, etc.


Dust Suppression Water Mist Cannon With Vertical Pitch Device Strong FlexibilityDust Suppression Water Mist Cannon With Vertical Pitch Device Strong Flexibility
Sprayer machine technical Data

Water fog cannon spray gun machine parameter:

ModelBS-30BS-40BS-50BS-60

Horizontal spray range
when no wind

25-30m35-40m45-50m55-60m
Power4.65kw5.45kw24.7530.25
Voltage380v380v380v380v
Water pump power2.2kw2.2kw5.5kw7.5kw
Fog size30-200μm30-200μm30-200μm30-200μm
Flow40-60L/min40-60L/min120L/min150L/min
Pressure2-4Mpa2-4Mpa2-8Mpa2-10Mpa
Horizontal rotation angle0-3600-3600-3600-360


Application of fog cannon machine

1. Environmental protection: City pm2.5/10 dust control, Disinfection epidemic prevention, City Demolition,Odor control at waste disposal & landfill sites,Humidifying, cooling and dust control on construction site, etc.

2. Industry dust suppression:Open pit mining blasting/digging/ load&transport dust , Port material storage yard dust , Wharf Bulk Ships loading&unloading dust, Iron & steel plant stockpile & slag disposal dust, Power plant coal storage yard dust, Conveyor belt blanking point dust, Coal mine crushing dust,Haul roads dust,Storage and handling of bulk materials dust, etc.

3. Agriculture protection:The sprayer can used for pest control in agriculture, orchard, garden areas,farmland, forest, road greening, grassland, pasture ,etc.

Dust Suppression Water Mist Cannon With Vertical Pitch Device Strong Flexibility
Details Discription of Water Sprayer Machine

Main Features:

1) Far throw distance with radial distance from 40-200 meters.
2) Small water consumption and energy saving,only 1/10 water consumption of which of the conventional spray equipment.
3) Excellent dust control effect and much better than conventional spraying equipment.
4) Wide coverage with 320°degree rotation radius,more advanced than conventional spray equipment.
5) Strong flexibility,can be made trailer-mounted or truck-mounted,which greatly improve efficiency and reducing equipment input quantities,more flexible and lower consumption than conventional spray equipment.
6) Flexible operation,optional manual control operation or remote control operation .
7) Good atomization and mist particle can be adjusted from 20um-150um according to customer’s requirement.


Packing&Delivery
Payment terms
We usually use T/T, L/C
T/T:T/T 30% in advance, the balance be paid after inspection before the delivery
Before delivery, we will send you the pictures of finished machines and welcome you to come to our factory for inspection
Way of packing
FCL&LCL export standard in 20/40feet container
FCL:Sea-worthy package,machine are fixed in container and the spare parts are packed in wooden boxes
Shipping
MSK/MSC/APL/EMC/PIL and so on
Warranty
12 months under normal use except for wearing parts

Company Information

Henan Baishun Machinery Equipment Co., Ltd product a wide wariety of throw distance of 20 meter, 30meter, 40 meter, 50 meter, 60 meter, 80 meter, 100 meter, 150 meter, 200 meter. Our company is committed to environmental protection.

The company attaches great importance to international technical exchanges and cooperation, has introduced advanced technology and craft from United States, Germany, Australia and other countries, establishes the international advanced production lines and first-class modern testing base.

FAQ

1.Q:Are you a factory or trading company?
A: We are a factory since 1993.
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Zhengzhou City, Henan Province, China. You can fly to Xinzheng airport directly. All our clients, from home or abroad, are warmly welcome to visit us!

3.Q:What is the material of your products?
A: The material is Steel A3. We can also choose material as customers’ requirements.
4.Q: What is the warranty time of your products?
A: The warranty time is 12months from the date of the commissioning, or 18months from the factory delivery, the first shall prevail. All quick-wear spare parts will be provided for free within the warranty period. After the warranty, we also can ensure that you can buy any necessary spare parts with favorable price within 5 years.
5.Q:How does your factory do regarding quality control?
A:"Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001:2008 authentication.
