Shenzhen Yideyi Technology Co., Ltd is a professional PCBA solution provider,specilizes in PCB production,components procurement,PCBA assembly and a series service of customized flexible LED strips.

Our products are widely used in meter, medical, solar energy, mobile, communication, industrial control, power electronics,security, consuming, computer, automotive, aerospace, military and so on. Over 75% of our products are exported to Europe, North America, Japan and other Asia Pacific countries. Based on many years of development, we have high-qualified management team, experienced R&D team and skilled employees,and possess advantaged supply chain, commitment to quality,and dedication to our customers service. Encouraging innovation and keeping improving. Besides achieving corporate and customer values, we also create a favorable atmosphere for employees to achieve personal values.

Our goal is to be the leading PCB solutions provider in the electronics industry with first-class products and services.

SMT PCBA capabilities:

• SMT assembly including BGA assembly

• Accepted SMD chips: 01005,BGA,QFP,QFN,TSOP

• Component height: 0.2-25mm

• Min packing: 0201

• Min distance among BGA : 0.25-2.0mm

• Min BGA size: 0.1-0.63mm

• Min QFP space: 0.35mm

• Min assembly size: (X*Y): 50*30mm

• Max assembly size: (X*Y): 350*550mm

• Pick-placement precision: ±0.01mm

• Placement capability: 0805, 0603, 0402, 0201

• High pin count press fit available

• SMT capacity per day: 800,000 point

Advantages:

• Strict product liability, taking IPC-A-160 standard

• Engineering pretreatment before production

• Production process control (5Ms)

• 100% E-test, 100% visual inspection, including IQC, IPQC, FQC, OQC

• 100% AOI inspection, including X-ray, 3D microscope and ICT

• High-voltage test, impedance control test

• Micro section, soldering capacity, thermal stress test, shocking test

• In-house PCB production

• No minimum order quantity and free sample

• Focus on low to medium volume production

• Quick and on-time delivery

Each board is carefully examined by our dedicated inspection team using AOI and high magnification viewers.

Using our X-Ray machine, we test PCBs to component level and all wiring is fully inspected and tested. Flash

testing and earth bonding tests can also be undertaken where required.

PCB Assembly Manufacturing Procedures:

Program Management

PCB Files → DCC → Program Organizing → Optimization → Checking

SMT Management

PCB Loader → Screen Printer → Checking → SMD Placement → Checking → Air Reflow → Vision Inspection → AOI → Keeping

PCBA Management

THT→Soldering Wave (Manual Welding) → Vision Inspection → ICT → Flash → FCT → Checking → Package → Shipment

Technical Requirement for PCB Assembly:

Professional Surface-mounting and Through-hole soldering Technology

Various sizes like 1206,0805,0603,0402,0201 components SMT technology

ICT(In Circuit Test),FCT(Functional Circuit Test) technology.

PCB Assembly With UL,CE,FCC,Rohs Approval

Nitrogen gas reflow soldering technology for SMT.

High Standard SMT&Solder Assembly Line

High density interconnected board placement technology capacity.

DIP capability:

• A-8 of semi-assembly work line with 3 set wave soldering machines

• B-4 of high/low-temperature burn-in test ovens for the burn-in tested required products

• All products are 100% inspected and tested during the DIP process

All our products follow IPC class and are approved by UL, RoHS and ISO9001. Also our executives and technicians are experienced people who have been engaged in PCB industry for more than twenty years so we have rich production management experience and professional PCB skills. We ensure the quality of PCB products by continuously introducing new equipment′s and new technologies and using high quality materials. With professional technicians we can provide early design consultation and technical support, so that customers can be more worry-free. With qualified and reliable products, advanced technology and value-added service, we won the trusts and supports of customers and established a good reputation in the industry.
