Entrance Automated Electronic Barrier Gates Vehicle Boom 304 Stainless Steel Housing
Entrance Automated Electronic Barrier Gates Vehicle Boom 304 Stainless Steel Housing
Specifications
Brand Name :
WEJOIN
Model Number :
DZJ
Certification :
CE ISO SGS
Place of Origin :
CHINA
MOQ :
1 set
Price :
negociate
Payment Terms :
T/T
Supply Ability :
10000 sets/month
Delivery Time :
3-5 working days
Packaging Details :
carton
motor material :
aluminum alloy
operating time :
3s, 6s
boom type :
straight folding fencing
housing material :
304 stainless steel
Color :
Yellow
Application :
parking lot
Description

Entrance Automated Electronic Barrier Gates Vehicle Boom 304 Stainless Steel Housing

Electronic Barrier Gates Quick Detail:

1.Wheel manual release.

In case of power off, rotate the wheel manual release on the bottom of the motor to raise the boom manually.

when power on, the motor will work normally.

2.Machine core with strong and double spring, make the machine core works more steadily.

3.Die-casting aluminum alloy motor, precise and good at thermal radiation.

4.Crank and rod structure makes the boom run placidly

5.Reversing on the obstacle

6.Auto-closing

7.Support the infrared photocell for antibumping function(optional)

8.Support external and internal vehicle loop detector(optional)

9.Traffic light interface(ac 22v,can support lamp with 40w)

10.Wire control / remote control(418MHZ)

11.Digital limit, more precise

12.Open, close control interface for parking system

13.Provide limit state signal to the parking system

Electronic Barrier Gates Features:

Voltage AC220V±10%,AC110V±10%
Frequency 50/60HZ
Rated power 200w
Relative humidity ≤90%
Working temperature -35℃~+60℃
Housing dimension(W*D*H) 335*285*925mm
Enclosure rating IP54
MTBF 2500000 times
Weight 40 KG

Technical data:

Model speed Arm Type Max Arm Length Arm Dimension
801J-13 3s straight 4.5m 45*100mm
801J-16 6s 6m
801J-23 3s 90º folding 3m
801J-26 6s 5m
801J-33 3s 180º folding 3m
801J-36 6s 5m
801J-46 6s 2 fencing 4m
801J-56 6s 3 fencing 3.5m

Entrance Automated Electronic Barrier Gates Vehicle Boom 304 Stainless Steel Housing
