system | Main Processor | GK7102 |
image sensor | GC1034/GC2053 |
Operation System | Embedded LINUX OS system |
Video | High Definition | 720P/1080P |
Video Compression | Smart H.264+ |
Rotation angle | NO |
Object tracking | Support |
low illumination | 0.1LUX/F1.2 |
picture Capture | Support |
Video Flip | Support |
Audio | Coding standard | G.711 |
Two-way Speech | Support |
Record management | Video file size | 2.5GB-4.5GB/Day |
Record Mode | Manual record, motion detection record, scheduled record, alarm record |
Video storage | TF Card/Cloud |
playback, back up | Support |
Alarm trigger | Video Push,Alarm recording,screen shot capture ,sending Email |
Network | Network Interface | NO |
WIFI | 802.11b/g/n |
Bitstream | Three Stream |
Network Protocol | Support TCP/IP,RTSP,ONVIF, etc |
transmission mode | P2P,Smart Cloud Sever |
WIFI connection | Sweep QR code,AP Hotspot Addition |
extend | TF Card | Maximum support 128GB TF card |
Reset key | Support |
power supply | Power | DC 5V 1.5A |
Power consumption | 5W |
work environment | Suitable place | Home,shop,School,factory; |
Installation mode | Flat put,Wall mounted,hoisting |
Working Temperature | -10℃-+55℃ |
Working humidity | 10%-90% |
Other | Camera lens | 3.6MM |
Lamp board | 6 pcs |
Product size | 60*65*115 (mm) |
