Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
Specifications
Brand Name :
ZHITIAN
Model Number :
135
Place of Origin :
CHINA
MOQ :
500mm
Price :
consult with
Payment Terms :
L/C, T/T
Supply Ability :
100000 mm/mouth
Delivery Time :
30-60 days
Packaging Details :
Wooden Box or Paper Box
Material :
CPM10V
Color :
Metal
Application :
Granulating Extruder
Experience :
20 years
Package :
Paper Box or Wooden Box
Hardness :
HRC60-62
Description

Extruder Screw Barrel Zsk135 Stainless Steel Twin Screw Cpm10V

Quick Details

Production name: Screw element Model Number: ZSK135
Extrusion equipment: Material: WR5 / SAM10/1.4112/SAM39
Place of Origin China Application Twin screw extruder machine
Production ability 300m / Per month Diameter 177mm

Product Description

Co-rotating twin screw elements for
-APV -KOBE -OMC
-Buhler -KraussMaffei -Theysohn
-Buss -Berstorff- -Toshiba
-Clextral -Labtech -USEON
-Lantai - others
-JSW -Leistritz
-Keya -Maris

Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine

We supply twin screw extruders Range 15.6 - 350mm

We can satisfy your different material needs:

According to appearance design,

Convey Screw Segment,Mixing Screw Segment,Kneading Block&disk,Transition Screw Element,Deep groave Transfer Element,Screw Element for side feeder,1/2/3-flighted Screw Element,OEM Special Screw Element.

Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine

According to Materical,

-For wear application:

Tool Steel:W6Mo5Cr4V2

PM-HIP material:WR5,WR13,WR14,CPM10V,CPM9V.

-For corrosion application:

38CrMoAla

PM-HIP material:WR4,WR13,WR14,CPM10V,CPM9V.

-For wear and corrosion application:

PM-HIP material:WR13,WR14,CPM10V,CPM9V.

-Other materials:

Stainless Steel:316L,440C etc.

Through the understanding of customers,recommend the most valuable material.

Production Process

Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine

NO.1

Workblank

Select high-quality raw materials

NO.2

Piecewise


According to the drawing section length

 Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine

NO.3

Hit bottom hole


Rough machining the bottom hole,and then pull spline

NO.4

Machining thread


Professional high-end processing equipment,rough machining threads

 Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine

NO.5

Finish machining thread

NO.6

Threading grinding


Further control of tolerance
Length:-0.01mm-+0.01mm
OD:-0.03mm-0mm
Transition arc:-0.02mm-+0.02mm

 Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine

Packing&Delivery

Packing Details: According to your order quantity packaging,shipping wooden boxes,air carton.

Delivery Details: 5-40days after order.

Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine

1.Rust-proof oil processing,

Prevent rust in transit.

2.Oiled paper packages,

Prevent oil dry.

3.Bubble wrap package,

Prevent collosions.
Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine Double Screw Extruder Elements For ZSK135 BOPET Film Brucker Machine
4.Special foam packaging. 5.Packing 6.Sealing

FAQ

How long does it take to get my products since I paid for them?

---According to yout order quantity,we will give you a reasonable delivery date.

Can I get the warranty of one year for free?

---If you need the warranty,you should pay for it.If not,do not worry ,we have confidence in our products.

How is your after-sale service?

---You will get our help in time as long as you find something wrong about our produces.Believe us,you deserve the best.

Are yuo responsible for the assembly?

---We will provide this service at your requst.
