We have 43 injection molding machines from 50-300 ton . Japan Fanuc, Taiwan YiZhan and China HongRui. We are professional manufacturer for special engineering resin such as PEEK,PAEK, , PPSU , PEI , LCP , PPS , PFA , PUDF , PCTG , PET , PA66 , PCS etc. Material temperature max 430C and mold temperature max 180C.

1. PEEK

Feature: Heating without harmful substances And heating without deflection.

Application: E-cigarette heating part And Carrier of gene detection instrument.

2. PPE

Feature: Specific permittivity and good weather resistance.

Application: 4G base station.

3. PEI

Feature: High precision, quick response.

Application: IC burn-in socket

4. PARA

Feature: 3D Directions screw structure And good appearance.

Application: Medical operation and Forceps handle.

5. PPSU

Feature: Structural strength and Transparency requirements.

Application: Medical chamber.

6. PBT

Feature: Press-fit terminals

insert molding

Application: Automotive sensor

Mould position

Generally refers to the positioning mechanism of the mold, that is, any mechanism that can obtain lateral core pulling or lateral parting and reset action to pull out the product's undercut, depression and other positions.

Positioning action principle and design essentialsedit

It uses the mold opening action of the molding to make the diagonal brace tip and the slider move relative to each other, so that the slider moves along the mold opening direction and the horizontal direction to make it free from the undercut. as the picture shows:
In the picture:
β = α +2 °～3 ° (to prevent interference when clamping the mold and reduce friction when opening the mold)
α ≦ 25 ° (α is the inclination angle of the diagonal brace pin)
L=1.5D (L is the mating length)
S=T+2 ～ 3mm (S is the horizontal movement distance of the slider; T is the finished product undercut)
S=(L1xsina- δ )/cos α (δ is the gap between the brace tip and the sliding block, generally 0.5MM;
L1 is the vertical distance of the brace tip in the slider)

Tolerance

Accuracy of grinding: 0.001 mm;
Accuracy of EDM: 0.002 mm;
Accuracy of Wire-cutting: 0.002mm;
Accuracy of CNC: 0.002mm
In short, the requirment of tolerance as customer's demand.
