Ungalvanized Steel Wire Rope For Cranes 6x7+FC With 6-48mm Wire Gauge
Ungalvanized Steel Wire Rope For Cranes 6x7+FC With 6-48mm Wire Gauge
Specifications
Brand Name :
FUXING
Model Number :
6x7+FC
Certification :
ISO9001, CE, Lloyd's, ISO14001, OHSAS18001
Place of Origin :
China
MOQ :
1 TONS
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3000 Tons per month
Delivery Time :
20-30 Days
Packaging Details :
Packed in Wooden Reel, 1000M or 2000M per Reel.
Steel Grade :
60# 65# 70# 72A
HS Code :
721730000
Standard :
ASTM, BS, DIN, GB, JIS
Wire Gauge :
6-48mm
Application :
Used for cable car, belt conveyer, cable way drawing and slope well winch
Surface :
Ungalvanized
Tensile Strength :
1570-1960MPA
Lay :
ZS Or Sz
Description

PRODUCTS DESCRIPTION:

1. Material: Carbon steel
2. Standard: DIN, GB, EN12385-4, AISI, BS, ASTM, JIS etc
3. T/S: 1570MPA, 1670MPA, 1770MPA, 1870MPA, 1960MPA
4. Delivery date: 10-30days after the order confirmation.

5. Diameter: from 0.15 mm to 80mm
6. With ISO and SGS Certificate
7. Welcome OEM orders

Packaging: Export packaging
Inner packing:
Wooden reel and craft paper

Outer packing:
Wooden pallet or according to requests

TECHNOLOGY DETAIL

Used for cable car, belt conveyer, cable way drawing and slope well winch

Nominal

Diameter

Approx Weight

(Kg/100m)

 Tensile Strength (N/mm2)
1570 1670 1770 1870
D(mm) Minimum Breaking Load (KN)
FC IWRC FC IWRC FC IWRC FC IWRC FC IWRC
6 12.6 13.9 18.7 20.2 19.9 21.5 21.1 22.8 22.3 24.1
7 17.2 19 25.5 27.6 27.1 29.3 28.7 31.1 30.4 32.8
8 22.5 24.8 33.3 36 35.4 38.3 37.6 40.6 39.7 42.9
9 28.4 31.3 42.2 45.6 44.9 48.6 47.6 51.5 50.3 54.4
10 35.1 38.7 52.1 56.4 55.4 60 58.8 63.5 62.1 67.1
11 42.5 46.8 63.1 68.2 67.1 72.5 71.1 76.9 75.1 81.2
12 50.5 55.7 75 81.2 79.9 86.3 84.6 91.5 89.4 96.7
13 59.3 65.4 88.1 95.2 93.7 101 99.3 107 105 113
14 68.8 75.8 102 110 109 118 115 124 122 132
16 89.8 99.1 133 144 142 153 150 163 159 172
18 114 125 169 183 180 194 190 206 201 218
20 140 155 208 225 222 240 235 254 248 268
22 170 187 252 273 268 290 284 308 300 325
24 202 223 300 325 319 345 338 366 358 387
26 237 262 352 381 375 405 397 430 420 454
28 275 303 409 442 435 470 461 498 487 526

PRODUCTION LINE
Ungalvanized Steel Wire Rope For Cranes 6x7+FC With 6-48mm Wire Gauge
Ungalvanized Steel Wire Rope For Cranes 6x7+FC With 6-48mm Wire Gauge

TEST EQUIPMENT

Ungalvanized Steel Wire Rope For Cranes 6x7+FC With 6-48mm Wire Gauge

Ungalvanized Steel Wire Rope For Cranes 6x7+FC With 6-48mm Wire Gauge

Ungalvanized Steel Wire Rope For Cranes 6x7+FC With 6-48mm Wire Gauge

Marketing and Services
We located in Hubei which is the thoroughfare of nine provinces, the company enjoys significant advantages in traffic location; our company is only 2 km from Hanjiang, 3 km from Hanyi Railway. We have our own logistics company, and can carry out the transportation through waterway, highway and railway. We have set up powerful marketing network, with more than 60 offices and distribution divisions. Adhering to the marketing principle of "Putting personal morality before work", we provide pre-sales, sales and after-sales services for the clients. Based on 24 hour tracking all the way, we can serve the companies in a prompt and considerate manner.
Ungalvanized Steel Wire Rope For Cranes 6x7+FC With 6-48mm Wire Gauge
