Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
Specifications
Brand Name :
uchi
Model Number :
WX4710-7R0K95L
Certification :
UL ROH
Place of Origin :
Made in Dongguan
MOQ :
10000
Price :
USD
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
10000000
Packaging Details :
box( L350*W350*H170)
Core :
G47*1.0
Wire :
0.08*105P*10.5TS
Sn :
sn99.3%
Cu :
0.7%
Temp :
25degree
Humidity :
70%
Description

Notching L wireless charging coils assembly WX4710-7R0K95L for smart tv or phone and notebook

1. DIMENSIONS(MM)

A(mm) 47.4Max
B (mm) 23.5+/-0.5
C(mm) 2.0～4.0
C1(mm) 95+/-5.0
E(mm) 8.0Ref
F(mm) 2.7Max
H(mm) 48+/-1.5
E(mm) 8.0Ref



2.MATERIAL:

a. CORE:G47*1.0 notching "L"
b. WIRE:∮0.08*105P*12.5TS
c. Sn:Sn99.3% Cu:0.7%
d. Yellow adhesive:1603
e. tape maroon mylar tape (8.0mm width)

Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L

3.ELECTRICAL DIAGRAM:

Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L


4. ELECTRICAL CHAR ACTERISTIC:

ITEM SPEC TEST EQUIPMENT TEST CONDITION
L 7.0uH+10% WK5237 OR EQU 100KHz/0.25V
DCR 60(mΩ)MAX 502BC
Q Value) 70 Min WK5237 OR EQU 100KHz/0.25V



5.SPECIFICATION NO:

WX 4710 -7R0 K 95L
① ② ③ ④ ⑤
①Product symbol:
②Dimmensions:
③Inductance : 2R2:2.2μH, R47:0.47μH,310:31uH,501:500uH,152:1.5mH
④Tolerance: J－±5% K－±10% M－±20% N－±30% P－MIN
⑤Length of Lead:06L: 6MM , 95L: 95MM










6.TEST DATA:

ELECTRICAL CHARACTERISTIC
ITEM L(μH) DCR(mΩ) Q
SPEC 7.0+/-10% 60MAX 50 Min
1 7.05 46.2 82
2 7.15 46.1 75
3 6.98 45.6 71
4 7.01 46 77
5 7.05 47 70
X 7.048 46.18 75
R 0.17 1.4 7.0



7.PACKAGING

a.quantity
b.packaing dimensions(mm)

used PE packing
Notching L Wireless Charging Receiver Coil For Smart Tv Or Phone And Notebook WX4710-7R0K95L
L W H
350MAX 350MAX 170MAX
c: Storage
Please be sure to the parts at 35℃or less,70%RH or less,and isolate the parts from sulphic and chloric atm osphere

8.RELIABILITY TEST

.1.STORAGE TEMPERATURE:

-40℃～85℃

.2.OPERATING TEMPERATURE RANGE :

-40℃～+85℃(CONTAIN HEATING COIL)

-40℃～+85℃

3.EXTERNAL APPEARANCE :

NO EXTERNAL DEFECTS CAN BE FOUND IN THE VISUAL INSPECTION.

4. TERMINAL STRENGTH :

FIXED INDUCTORS,ONE END OF THE ELECTRODE WITH 0.45KG PULLING FORCE,GUIDED THE NEEDLE DOES NOT FALL OFF.

5.INSULATING RESISTANCE :

THE INSULATION RESISTANCE SHOULD BE OVER 1000MΩ WHEN D.C.100V IS APPLIED TO THE WINDING –CORE. MEANWHILE NO STRUCTURE AND ELECTRIC DEFECTS SHOULD BE FOUND FOR 1 MINUTE.

6. HUMIDITY TEST :

INDUCTANCE DEVIATION IS WITHIN ±10.0% AND NO STRUCTURE AND ELECTRIC DEFECTS CAN BE FOUND AFTER 96±2hours TEST UNDER THE CONDITIONOF RELATIVE HUMIDITY OF 90～95% AND TEMPERATURE OF 40±5℃. AND 1 HOUR STORAGE UNDER ROOM AMBIENT CONDITIONS AFTER THE DEVICE IS WIPED WITH DRY CLOTH.

7. VIBRATION TEST :

INDUCTANCE DEVIATION IS WITHIN ±10.0％ AFTER 1 HOUR SWEEPING VIBRATION IN EACH THREE DIRECTIONS. NAMELY, FREQUENCY IS10～55Hz ANDTHE AMPLITUDE OF 1MINUTE CYCLE IS 1.5mm .






























9.Background

Inductive Coupling: good coupling between two coils, a transmitter coil and a receiver coil. An alternating current in the transmitter coil generates a magnetic field which induces a voltage in the receiver coil. This voltage can be used to power a mobile device or charge a battery. It is ideal for wireless charging transmitter coil assembly and increase the charging efficiency.

10.Features

Wireless charging transmitter coil assembly (Tx - coil)
Litz wire winding Shield by Ni-Zn ferrite material
Compliance with Qi standard of WPC

11.Applications

Mobile Phones
Battery or battery Chargers
Cameras
MP3 /PMP
MID's
Hand Held Devices
Gaming devices
