Specifications
Model Number :
SFB Series
Certification :
UL,CUL,PSE,KTL.
Place of Origin :
Dongguan,Guangdong,China
MOQ :
3000PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
3,000,000pcs per day
Delivery Time :
10 days
Packaging Details :
Tape in ammo;3000 fuses per poly bag, 10 inner boxes per outer carton.
Product Name :
Axial Leaded Fuse
Series :
SFB
Blow type :
Fast-acting
Current range :
100mA~15A
Voltage ratings :
125V/250V
Standards :
UL 248 -1 / -14
Breaking Capacity :
50A@125V/250VAC
Body Dimension :
Dia 3x Length 7mm
Package :
Tape in ammo;3000 fuses per poly bag, 10 inner boxes per outer carton.
Body Encapsulated :
Epoxy Coated
Lead wire :
Tin Plated Copper
Cap :
Nickel Plated Brass
Fuse element :
Alloy wire
Body :
Non-Transparent Ceramic Tube
Operating Temperature :
-55℃～+125℃
Lead shape :
Axial
Description

SFB Series PICO Fast-Acting Subminiature Axial Leaded Fuse 100mA-15A 125V 250V With Space-saving Subminiature Package

PDF Specification Datasheet Download Link : SFB Series PICO Fast-Acting Subminiature Axial Lea...

Description

SFB Series PICO Fast-Acting Subminiature Axial Leaded Fuse is designed to meet an extensive array of performance characteristics in a space-saving subminiature package.Suitable for all kinds of electronic devices’ circuit over current protection. Widely used in Lighting, Power supply and Adapter applications, etc.
SFB Series Time Delay Glass Fuses PICO Fast Acting Subminiature Axial Lead Fuse 100mA-15A
Feature
  • Fast-acting
  • Small size
  • High current rating
  • RoHS compliant
  • Wide operating temperature range
  • Low temperature rerating
Application
Power supply
PC server
Networking equipment
Storage system
Standards and Certificates
Standards:In accordance with UL 248 -1 / -14.
Certification range

Voltage Rating

Agency

Ampere Range

Agency File Number
125V/250V UL 100mA ~ 6.3A E340427(JDYX2)
C-UL 100mA ~ 6.3A E340427(JDYX8)
PSE 100mA ~ 6.3A Pending
KTL 100mA ~ 6.3A Pending
Dimension unit:mm
SFB Series Time Delay Glass Fuses PICO Fast Acting Subminiature Axial Lead Fuse 100mA-15A
SFB Series Time Delay Glass Fuses PICO Fast Acting Subminiature Axial Lead Fuse 100mA-15A
Material info

NO.

Part Name

Material
1

Body Encapsulated

Epoxy Coated
2

Lead wire

Tin Plated Copper
3

Cap

Nickel Plated Brass
④

Fuse element

Alloy wire
⑤

Body

Non-Transparent Ceramic Tube
Specification

Part No.

Ampere

Rating

Voltage

Rating

Breaking

Capacity

I2TMelting

Integral(A2.S)
SFB0100A/B 100mA 250V/125V 50A@125V/250VAC 0.001
SFB0125A/B 125mA 250V/125V 50A@125V/250VAC 0.002
SFB0160A/B 160mA 250V/125V 50A@125V/250VAC 0.003
SFB0200A/B 200mA 250V/125V 50A@125V/250VAC 0.006
SFB0250A/B 250mA 250V/125V 50A@125V/250VAC 0.012
SFB0300A/B 300mA 250V/125V 50A@125V/250VAC 0.016
SFB0315A/B 315mA 250V/125V 50A@125V/250VAC 0.019
SFB0350A/B 350mA 250V/125V 50A@125V/250VAC 0.022
SFB0400A/B 400mA 250V/125V 50A@125V/250VAC 0.035
SFB0500A/B 500mA 250V/125V 50A@125V/250VAC 0.047
SFB0630A/B 630mA 250V/125V 50A@125V/250VAC 0.056
SFB0750A/B 750mA 250V/125V 50A@125V/250VAC 0.078
SFB0800A/B 800mA 250V/125V 50A@125V/250VAC 0.098
SFB1100A/B 1A 250V/125V 50A@125V/250VAC 0.3
SFB1125A/B 1.25A 250V/125V 50A@125V/250VAC 0.5
SFB1150A/B 1.5A 250V/125V 50A@125V/250VAC 0.6
SFB1160A/B 1.6A 250V/125V 50A@125V/250VAC 0.8
SFB1200A/B 2A 250V/125V 50A@125V/250VAC 1.2
SFB1250A/B 2.5A 250V/125V 50A@125V/250VAC 2
SFB1300A/B 3A 250V/125V 50A@125V/250VAC 2.5
SFB1315A/B 3.15A 250V/125V 50A@125V/250VAC 2.9
SFB1350A/B 3.5A 250V/125V 50A@125V/250VAC 3.1
SFB1400A/B 4A 250V/125V 50A@125V/250VAC 4.2
SFB1500A/B 5A 250V/125V 50A@125V/250VAC 7.2
SFB1630A/B 6.3A 250V/125V 50A@125V/250VAC 12
SFB1700A/B 7A 250V/125V 50A@125V/250VAC 15
SFB1800A/B 8A 250V/125V 50A@125V/250VAC 16
SFB2100A/B 10A 250V/125V 50A@125V/250VAC 18
SFB2120A/B 12A 250V/125V 50A@125V/250VAC 20
SFB2150A/B 15A 250V/125V 50A@125V/250VAC 25
Fusing Characteristics

% of Ampere Rating(In)

Blowing Time
100% * In 4 hours Min
200% * In 60 sec Max

Average Time Current Curves

SECONDS

SFB Series Time Delay Glass Fuses PICO Fast Acting Subminiature Axial Lead Fuse 100mA-15A

CURRENT IN AMPERES

Package

Packing Quantity

A. Taped packing:

3000 fuses per poly bag

10 inner boxes per outer carton

Inner box : L275±2 * W80±2 * H70±2

Outer carton : L390±5 * W240±5 * H250±5
