ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics
ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics
ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics
ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics
ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics
ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics
Specifications
Brand Name :
SHIHENG
Model Number :
MF57
Certification :
ROHS etc.
Place of Origin :
CHINA
MOQ :
1000PCS
Price :
Negotiable
Payment Terms :
Western Union, MoneyGram, T/T,Paypal
Supply Ability :
1 Billion per year
Delivery Time :
2 weeks
Packaging Details :
Bulk
Type :
MF57 Series Auto NTC Thermistor
R25 :
0.22~10 KOhm
Resistance tolerance :
±1%,±3%,±5%,±10%,±20%
Beta Value :
2700~4700 K
Beta tolerance :
±1%,±2%,±3%,±5%
Rated power :
0.2~0.5W
Thermal time constant :
≤50/60mW
Dissipation Coef. :
3.5~13mW/C
Operating Temp :
-40~+125 Degree
Model :
MF57A,MF57B,MF57C
Description

ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics

PDF Specification Download Link : MF57 Temperature Measurement NTC Thermistor Specia...

General

MF57 Series thermistor used for automotive electronics (diesel locomotive, large motor, oil-immersed transformer) of the cooling system for fixed point temperature sensing element, temperature measurement can also be applied to other places.

ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics

Application

  • Temperature sensing and measuring in automobile cooling system
  • Larger power electric engine
  • Combustion engine
  • Oil transformer etc.
  • Also applicable for temperature measuring on other occasions.

Features

  1. High reliability and long life
  2. High sensibility, easy to be replaced
  3. Wide temperature range
  4. For Automobile use

Dimension (mm)

ISO TS16949 2009 Certificated High Precision MF57 Series Auto NTC Thermistor For Automotive Electronics

Main parameters

Part number Rated Resistance R25 B value

Rated Power

(W)

Thermal time constant

(sec)

Dissi. Coef.

(mW/℃)

Operating Temp.

(℃)
Range (Ω) Tolerance(％) Rated value (K) Tolerance(％)
MF57A 0.22K~10K

±1％

±3％

±5％

 2700~4700 (25/50℃)

±1％

±3％

±5％

0.3

0.4

0.5

 ≤60 6~13 -40~+125
MF57B 0.4K~10K

±1％

±10％

±20％

 3600~4500 (25/85℃)

±1％

±2％

±3％

 0.2 ≤50 ≥3.5
MF57C 0.4K~2K

±5％

±10％

±20％

 2400~3000 (25/50℃)

±5％

Quality system

Quality System Name File Number Approved Date
ISO9001:2008 Quality Management System 01110Q20002R3M Feb,2002
ISO14001:2004 Environment Management System 01110E20031R1M Jan,2017
ISO/TS16949:2009 Quality Management System CNTS016905 Sep,2014
GB/T29490-2013 Intellectual Property Right Management System 18115IP0255ROM Nov,2015
