Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Specifications
Brand Name :
broadradio
Model Number :
BRA-07
Place of Origin :
China shenzhen
MOQ :
50pcs
Price :
Negotiable
Payment Terms :
T/T，PayPal
Delivery Time :
3-5work days
Packaging Details :
Standard Export Carton, Plastic inner box
product name :
small RFID Antenna,Handheld antenna
Frequency Range :
902MHz～928MHz
VSWR :
≤1.3:1
Gain :
> 3 dBic
Polarization :
Circular Polarization
Axial ratio :
<3 dB
Relative humidity :
5%～95%
Impedance :
50±1Ω
Description

BRA-07 size 61×61×16.3 mm small RFID Antenna for UHF RFID handset antenna Weight 30g

the main test capabilities

Antenna gain

Antenna directivity

Beamwidth

Antenna efficiency

Radiated power

Label sensitivity

Label performance

Product Features

1. Universal antenna for high gain, miniaturization, low VSWR and other terminal applications.
2, superior mechanical performance, small size, suitable for a variety of harsh environments.
3, the antenna uses circular polarization design, gain 3dBic, small size, high recognition sensitivity

4, BRA-07 Antenna is of convenient application in UHF RFID handheld reader.

Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna

Mechanical Specifications

Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna
Performance Specifications
Frequency Range
860MHz～960MHz
VSWR
≤1.3:1
Gain
> 3 dBic
Axial ratio
<3 dB
Polarization
Circular Polarization
Relative humidity
5%～95%
Impedance
50±1Ω
Connector Type
SMA (IPX optional)
Mechanical Specifications
Size
61 mm×61 mm×16.3 mm
Weight
30g
Material
FR4, stainless steel
Color
green
Production Class
IP54
Operating Temperature
-40℃~+ 85℃
Storage Temperature
-40℃~+ 85℃

Low VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset AntennaLow VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset AntennaLow VSWR Small Uhf Antenna Size 61×61×16.3mm For UHF RFID Handset Antenna

Shenzhen Broadradio RFID Technology Co.,LTD. is a global leader inUHF RFID hardware solutions,

belongs to the national hightech enterprises, committed to RFID antenna, RFID tags, RFID access

control and RFID integrated equipment products R & D, production and sales. Products are widely

used in archives, books, electricity, logistics, warehousing, retail, assets, medical, manufacturing and

other fields. The company advocates the strategy of "demandguided application, applicationdriven

products", pays attention to customer needs, and provides customers with overall RFID (field) solutions

in an all-round way with the support of a professional team and rich project experience.
