NBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction Hose
NBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction Hose
NBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction Hose
NBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction Hose
NBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction Hose
NBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction Hose
Specifications
Brand Name :
Zebung
Model Number :
ZBHO01
Place of Origin :
China
MOQ :
300m
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
5000m per day
Delivery Time :
Quantification
Packaging Details :
Plastic woven bags
Inner :
NBR
Cover :
NBR
Reinforcement :
High Tensile textile cord
Color :
Black
Safety Factor :
3:1
W.P :
10bar
Description

Oil Resistant Flexible Textile Braided Hydraulic Oil Rubber Hose

1. Construction:

Inner Tube: Black NBR synthetic rubber.

Reinforcement: High tensile plied synthetic textile

Cover: Nitrile(NBR), NEOPRENE(CR) oil-resistant rubber (fabric surface).

NBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction HoseNBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction Hose

2. Temperature: -20°C~+80°C

3. Application:

Designed for hydraulic support, oil exploration, suitable to engineer construction, crane transport, forging metallurgy,

mining equipment, ships, injection molding machinery, agricultural machinery various machine tools.

NBR Rubber Hydraulic Oil Hose , Flexible Textile Braided Oil Suction Hose

4. Characteristics: flexible; abrasion, aging, oil, weather, ozone resistance

5. Length: 40m/50m/60m/100m or as request

6. Specification:

I.D.
O.D.
W.P.
B.P.
B.R.
Weight
Length
mm inch mm psi bar psi bar mm kg/m ft m
6 1/4" 14 300 20 900 60 60 0.18 328 100
8 5/16" 16 300 20 900 60 80 0.21 328 100
10 3/8" 18 300 20 900 60 100 0.25 328 100
13 1/2" 22 300 20 900 60 130 0.36 328 100
16 5/8" 26 300 20 900 60 160 0.48 328 100
19 3/4" 29 300 20 900 60 190 0.55 328 100
25 1" 36 300 20 900 60 250 0.78 328 100
32 1-1/4" 44 300 20 900 60 250 1.06 200 61
38 1-1/2" 52 300 20 900 60 300 1.41 200 61
51 2" 65 300 20 900 60 400 1.82 200 61
64 2-1/2" 78 300 20 900 60 500 2.3 200 61
76 3" 90 300 20 900 60 600 2.68 200 61
102 4" 119 300 20 900 60 800 4.21 200 61
