Diesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber Material
Diesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber Material
Diesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber Material
Diesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber Material
Diesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber Material
Diesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber Material
Specifications
Brand Name :
Zebung
Model Number :
ZBFO01
Place of Origin :
China
MOQ :
300m
Price :
negotiated by specific quantity
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1200m per day
Delivery Time :
8-10days
Packaging Details :
white Plastic or blue woven bags
Certification :
ISO9001
Tube :
Nitrile rubber
Safety Factor :
3:1 ID-BP
Cover :
NBR Rubber
Temperature :
-20 to +120°C
Description

Cloth Covered Nitrile Anti-static Flexible Diesel/Fuel Oil Discharge Hose

Fuel Oil Discharge Hose also called flexible reinforced oil hose, fuel oil discharge hose is

a type of flexible hose for discharge of oil with aromatic content. Compared with hydraulic

oil hose, the fuel oil rubber hose has inserted copper wire for ground connection and

eliminating static electricity. The inner and outer rubber material has excellent oil, abrasion

and wear resistance performance.

Additional, it has up to 50% aromatic content resistant performance for heavy duty applications.

Diesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber Material

Fuel Oil Discharge Hose Construction:
Tube: Black, smooth, Nitrile.
Reinforcement: Multi plies high strength synthetic fabric, copper wire
Cover: Black, wrapped surface, weather and ozone resistant, synthetic rubber.

I.D. O.D. W.P. B.P. B.R. Weight Length
mm inch mm psi bar psi bar mm kg/m ft m
6 1/4" 14 300 20 900 60 60 0.18 328 100
8 5/16" 16 300 20 900 60 80 0.21 328 100
10 3/8" 18 300 20 900 60 100 0.25 328 100
13 1/2" 22 300 20 900 60 130 0.36 328 100
16 5/8" 26 300 20 900 60 160 0.48 328 100
19 3/4" 29 300 20 900 60 190 0.55 328 100
25 1" 36 300 20 900 60 250 0.78 328 100
32 1-1/4" 44 300 20 900 60 250 1.06 200 61
38 1-1/2" 52 300 20 900 60 300 1.41 200 61
51 2" 65 300 20 900 60 400 1.82 200 61
64 2-1/2" 78 300 20 900 60 500 2.3 200 61
76 3" 90 300 20 900 60 600 2.68 200 61
102 4" 119 300 20 900 60 800 4.21 200 61

Fuel Oil Discharge Hose Application:
Softwall hose Designed for the discharge of petroleum-based products, diesel, gasoline, lubricants, fuel, with aromatic content up to 50%.

Fuel Oil Discharge Hose Temperature: -35°C to +80°C

Fuel Oil Discharge Hose Characteristic:
Weather and abrasion resistant cover
Flexible and less distortion
For aromatic content up to 50%

Diesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber MaterialDiesel / Fuel Oil Suction And Discharge Hose Cloth Covered Nitrile rubber Material
