Multipurpose Flexible Rubber 60meter UHMWPE Chemical Hose Acid And Alkali Resistance
Multipurpose Flexible Rubber 60meter UHMWPE Chemical Hose Acid And Alkali Resistance
Multipurpose Flexible Rubber 60meter UHMWPE Chemical Hose Acid And Alkali Resistance
Multipurpose Flexible Rubber 60meter UHMWPE Chemical Hose Acid And Alkali Resistance
Multipurpose Flexible Rubber 60meter UHMWPE Chemical Hose Acid And Alkali Resistance
Multipurpose Flexible Rubber 60meter UHMWPE Chemical Hose Acid And Alkali Resistance
Specifications
Brand Name :
Zebung
Model Number :
ZB-UH-04
Certification :
ISO9001
Place of Origin :
China
MOQ :
300m
Price :
Negotiation
Payment Terms :
L/C, T/T, D/A, Western Union
Supply Ability :
30000M/DAY
Delivery Time :
7days
Packaging Details :
plastic transparent film and color woven bag
Name :
Customer logo UHMWPE Multipurpose Chemical flexible rubber hose acid and alkali resistance hose
W.P :
150PSI
Tube :
UHMW
Reinforcement :
high tensile textile cord with steel wire helix
Surface :
fabric Wrapped
Length :
40m 60m or customized length
Description

Customer logo UHMWPE Multipurpose Chemical flexible rubber hose acid and alkali resistance hose

Applications:

Versatile suction and delivery hose specifically designed to convey a wide range of chemicals (solvents and corrosive liquids), pharmaceutical, beverage, dairy, alcohol and other alimentary products. The lining of polyethylene rubber hose can transport concentrated nitric acid, sulfuric acid, hydrochloric acid, inner wall smooth, self-run good; inside and outside the rubber with natural and smooth rubber compound material, the middle layer using imported polyester fiber, work pressure can be based on customer requirements Made of wire weaving and wire weaving, or the use of negative pressure spiral wire plus the environment, this product is only the price of similar imported products 1/3, tetrafluoroethane pipe prices are 1/3, the service life and PTFE tube length , Bending radius of the tetrafluoroethane pipe 1/2, easy to install.


Construction:
Tube: UHMWPE (Ultra High Molecular Weight Polyethylene)
Reinforcement: Multiple textile plies with dual helix wire, antistatic copper wire
Cover: Corrugated black or blue EPDM compound. - abrasion and ozone resistant
Temperature range: -40 °C~+120 °C (-40 °F +248 °F)

Specification:

I.D O.D W.P B.P Bend Radius Weight Length
mm inch mm Psi bar bar mm kg/m m
19 3/4 29 150 10 30 228 0.6 100
25 1 35 150 10 30 300 0.93 100
32 1-1/5 42 150 10 30 320 1.25 60
38 1-1/2 48 150 10 30 380 1.47 60
51 2 64 150 10 30 400 1.92 60
64 2-1/2 78 150 10 30 512 2.4 60
76 3 90 150 10 30 532 2.9 60
102 4 117 150 10 30 630 3.92 30
127 5 143 150 10 30 760 6.5 30
152 6 168 150 10 30 912 7.7 30
NOTE: Other sizes, pressure and colors available on request.
