Chrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 Rings
Chrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 Rings
Chrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 Rings
Chrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 Rings
Chrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 Rings
Chrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 Rings
Specifications
Brand Name :
UIB
Model Number :
3309 2RS
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1000PCS
Price :
negotiable
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
10000pcs per month
Delivery Time :
5-8 weeks
Packaging Details :
UIB color box, or industrial package as per buyer request
Bearing material :
chrome steel GCR15, 52100
Bearing precision :
ABEC-1. ABEC-3, P0, P6
Applicant :
agriculture machine bearing
Bearing weight :
1.42KG
Bearing size :
45*100*39.7mm
work life :
3 years
static load Cr (KN) :
66.1
dynamic load Cor (KN) :
67.3
Description

Chrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 Rings

Our motorcycle bearing 3309 product advantage:

We using standard bearing steel for rings and roller, strict heat treatment for bearing inner rings and bearin external ring;

We have steel cage and nylon material cage both available, steel cage is much more heavy,and nylon cage is much more light and more durable.

Bearing external shage size tolerance guantee to +/-0.001mm,

Bearing rings Hardness HRC60~62,

We also could do customized size from our factory: Seller provide bearing finall production drawing for mutral confirmation. Only after order confirmed,and seller received buyer deposit.

precision taper roller bearing 3309,3300 series Product specifications and parameter data

bearing type ISO bearing NO. OLD bearing NO. ID OD WIDTH Cr Cor grease lubricated speed oil lubricated speed weight
(mm) (mm) (mm) (kN) (kN) (r/min) (r/min) (kg)
angular contact bearing 3304 3056304 20 52 22.2 20.8 18.4 8200 11000 0.23
angular contact bearing 3305 3056305 25 62 25.4 28.9 26.5 6800 9100 0.369
angular contact bearing 3306 3056306 30 72 30.2 38.1 36.1 5800 7800 0.585
angular contact bearing 3307 3056307 35 80 34.9 48.6 46.8 5200 7000 0.816
angular contact bearing 3308 3056308 40 90 36.5 54.1 53.8 4600 6100 1.07
angular contact bearing 3309 3056309 45 100 39.7 66.1 67.3 4100 5500 1.42
angular contact bearing 3302 3056302 15 42 19 15.2 11.9 10000 14000 0.132
angular contact bearing 3304A-Z - 20 52 22.2 - - - - -
angular contact bearing 3305A 3256305 25 62 25.4 32.7 20.8 6900 9200 0.34
angular contact bearing 3305A-2RS - 25 62 25.4 - - - - -
angular contact bearing 3305A-2Z - 25 62 25.4 - - - - -
angular contact bearing 3305A-RS - 25 62 25.4 - - - - -
angular contact bearing 3305A-Z - 25 62 25.4 - - - - -
angular contact bearing 3306A 3256306 30 72 30.2 41 28.5 5800 7700 0.51
angular contact bearing 3306A-2RS - 30 72 30.2 - - - - -
angular contact bearing 3306A-2Z - 30 72 30.2 - - - - -
angular contact bearing 3306A-RS - 30 72 30.2 - - - - -
angular contact bearing 3306A-Z - 30 72 30.2 - - - - -
angular contact bearing 3307A 3256307 35 80 34.9 51.2 36.2 5100 6800 0.79
angular contact bearing 3307A-2RS - 35 80 34.9 - - - - -
angular contact bearing 3307A-2Z - 35 80 34.9 - - - - -
angular contact bearing 3307A-RS - 35 80 34.9 - - - - -
angular contact bearing 3307A-Z - 35 80 34.9 - - - - -
angular contact bearing 3308A 3256308 40 90 36.5 62.7 45.4 4600 6100 1.05
angular contact bearing 3308A-2RS - 40 90 36.3 - - - - -
angular contact bearing 3308A-2Z - 40 90 36.5 - - - - -
angular contact bearing 3308A-RS - 40 90 36.5 - - - - -
angular contact bearing 3308A-Z - 40 90 36.5 - - - - -
angular contact bearing 3309A 3256309 45 100 39.7 75.1 55.7 4100 5500 1.42

Chrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 RingsChrome Steel GCR15 Agriculture Angular Contact Bearings 3309 2RS With HRC60 HRC62 Rings

Welcome you to contact us for more information about our other angular contact bearing!
