High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings
High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings
High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings
High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings
High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings
High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings
High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings
High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings
Specifications
Brand Name :
UIB
Model Number :
30206
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
100PCS
Price :
negotiable
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
10000pcs per month
Delivery Time :
5-8 weeks
Packaging Details :
UIB color box, or industrial package as per buyer request
Bearing material :
chrome steel GCR15, 52100
Roller number :
17
Applicant :
motorcycle bearing
Bearing weight :
0.233KG
Dynamic load :
45.37KN
Static load :
50.48 KN
Description

High Speed 52100 Chrome Steel Roller Bearing , Single Row Motorcycle Wheel Bearings

Our motorcycle bearing 30205 product advantage:

We using standard bearing steel for rings and roller, strict heat treatment for bearing inner rings and bearin external ring;

Tips on quality: rollers has polished surface is much better then without polished finish rollers. Price only a little different but quality improve quite a lot.

Bearing external shage size tolerance guantee to +/-0.001mm,

Bearing rings Hardness HRC60~62,

We also could do customized size from our factory: Seller provide bearing finall production drawing for mutral confirmation. Only after order confirmed,and seller received buyer deposit.

Our taper roller bearing factory advantage:

Can produce 30 mm ~ 250 mm outside diameter, more than two hundred models, PO, P6, P5 three precision grade series.

Single row, double row taper roller bearings and cylindrical roller bearings could produce.

The product can meet the needs of the host and maintenance. We also exported to Europe, North America a dozen industrial developed countries.

precision taper roller bearing 30205 Product specifications and data

bearing type ISO bearing NO. OLD bearing NO. ID OD WIDTH Cr Cor grease lubricated speed oil lubricated speed weight
(mm) (mm) (mm) (kN) (kN) (r/min) (r/min) (kg)
taper roller bearing 30202 7202E 15 35 11 14.9 13.4 12000 16000 0.053
taper roller bearing 30244 7244E 220 400 73 — — — — 35.5
taper roller bearing 30340 7340E 200 420 80 1120 1450 820 1100 53.5
taper roller bearing 30352 7352E 260 540 114 — — — — 108
taper roller bearing 32205 7505 25 52 19.25 — — — — 0.174
taper roller bearing 30302 7302E 15 42 13 22.8 21.5 9000 12000 0.094
taper roller bearing 30203 7203E 17 40 12 20.8 21.8 9000 12000 0.079
taper roller bearing 30303 7303E 17 47 14 28.2 27.2 8500 11000 0.129
taper roller bearing 32303 7603E 17 47 19 31.9 29.9 9400 13000 0.17
taper roller bearing 32904 2007904E 20 37 12 13.2 17.5 9500 13000 0.056
taper roller bearing 32004 2007104E 20 42 15 25 28.2 8500 11000 0.095
taper roller bearing 30204 7204E 20 47 14 28.2 30.5 8000 10000 0.126
taper roller bearing 30304 7304E 20 52 15 30.5 28.4 8300 11000 0.17
taper roller bearing 32304 7604E 20 52 21 42.8 46.2 7500 9500 0.23
taper roller bearing 329/22 - 22 40 12 15 20 8500 11000 0.065
taper roller bearing 320/22 20071/22E 22 44 15 26 30.2 8000 10000 0.1
taper roller bearing 32905 2007905E 25 42 12 16 21 6300 10000 0.064
taper roller bearing 32005 2007105E 25 47 15 28 34 7500 9500 0.11
taper roller bearing 33005 3007105E 25 47 17 32.5 42.5 7500 9500 0.129
taper roller bearing 30205 7205E 25 52 15 32.2 37 7000 9000 0.154
taper roller bearing 33205 3007205E 25 52 22 47 55.8 7000 9000 0.216
taper roller bearing 30305 7305E 25 62 17 46.8 48 6300 8000 0.263
taper roller bearing 31305 27305E 25 62 17 40.5 46 6300 8000 0.262
taper roller bearing 32305 7605E 25 62 24 61.5 68.8 6300 8000 0.368
taper roller bearing 329/28 - 28 45 12 16.8 22.8 750D 9500 0.069
taper roller bearing 320/28 20071/28E 28 52 16 31.5 40.5 6700 8500 0.142
taper roller bearing 332/28 30072/28E 28 58 24 58 68.2 6300 8000 0.286
taper roller bearing 32906 2007906E 30 47 12 17 23.2 7000 9000 0.072
taper roller bearing 32006X2 2007106X 30 55 16 27.8 35.5 6300 8000 0.16
taper roller bearing 32006 2007106E 30 55 17 35.8 46.8 6300 8000 0.17
taper roller bearing 33006 3007106E 30 55 20 43.8 58.8 6300 8000 0.201
taper roller bearing 30206 7206E 30 62 17.5 43.2 50.5 6000 7500 0.231
taper roller bearing 32206 7506E 30 62 20 51.8 63.8 6000 7500 0.287
taper roller bearing 33206 3007206E 30 62 25 63.8 75.5 6000 7500 0.342
taper roller bearing 30306 7306E 30 72 21 59 63 5600 7000 0.387
taper roller bearing 23334 7634 170 360 120 - - - - -
taper roller bearing 31306 27306E 30 72 21 52.5 60.5 5600 7000 0.392
taper roller bearing 32306 7606E 30 72 27 81.5 96.5 5600 7000 0.562
taper roller bearing 329/32 - 32 52 14 23.8 32.5 6300 8000 0.106
taper roller bearing 320/32 20071/32E 32 58 17 36.5 49.2 6000 7500 0.187
taper roller bearing 332/32 30072/32E 32 65 26 68.8 82.2 5600 7000 0.385
taper roller bearing 32907 2007907E 35 55 14 25.8 34.8 6000 7500 0.114
taper roller bearing 32007X2 2007117E 35 62 17 33.8 47.2 5600 7000 0.21
taper roller bearing 32007 2007107E 35 62 18 43.2 59.2 5600 7000 0.224
taper roller bearing 33007 3007107E 35 62 20 40.8 53.8 6200 8200 0.25
taper roller bearing 30207 7207E 35 72 17 54.2 63.5 5300 6700 0.331
taper roller bearing 32207 7507E 35 72 23 70.5 89.5 5300 6700 0.445
taper roller bearing 33207 3007207E 35 72 28 82.5 102 5300 6700 0.515
taper roller bearing 30307 7307E 35 80 21 75.2 82.5 5000 6300 0.515
taper roller bearing 31307 27307E 35 80 21 65.8 76.8 5000 6300 0.514
taper roller bearing 32307 7607E 35 80 31 99 118 5000 6300 0.763
taper roller bearing 32908X2 2007908 40 62 14 21.2 28.2 5600 7000 0.14
taper roller bearing 32908 2007908E 40 62 15 31.5 46 5600 7000 0.155
taper roller bearing 32008X2 - 40 68 18 39.8 55.2 5300 6700 0.27
taper roller bearing 32008 2007108E 40 68 19 51.8 71 5300 6700 0.267
taper roller bearing 33008 3007108E 40 68 22 60.2 79.5 5300 6700 0.306
taper roller bearing 33108 3007708E 40 75 26 84.8 110 5000 6300 0.496
taper roller bearing 30208 7208E 40 80 18 63 74 5000 6300 0.422
taper roller bearing 32208 7508E 40 80 23 77.8 97.2 5000 6300 0.532
taper roller bearing 33208 3007208E 40 80 32 105 135 5000 6300 0.715
taper roller bearing 30308 7308E 40 90 23 90.8 108 4500 5600 0.747
taper roller bearing 31308 27308E 40 90 23 81.5 96.5 4500 5600 0.727
taper roller bearing 32308 7608E 40 90 33 115 148 4500 5600 1.04
taper roller bearing 32909X2 - 45 68 14 22.2 32.8 5300 6700 —
taper roller bearing 32909 7007909E 45 68 15 32 48.5 5300 6700 0.18
taper roller bearing 32009X2 2007109X 45 75 19 44.5 62.5 5000 6300 0.32
taper roller bearing 32009 2007109E 45 75 20 58.5 81.5 5000 6300 0.337
taper roller bearing 33009 3007109E 45 75 24 72.5 100 5000 6300 0.398
taper roller bearing 33109 3007709E 45 80 26 87 118 4500 5600 0.535
taper roller bearing 30209 7209E 45 85 19 67.8 83.5 4500 5600 0.474
taper roller bearing 32209 7509E 45 85 23 80.8 105 4500 5600 0.573
taper roller bearing 33209 3007209E 45 85 32 110 145 4500 5600 0.771
taper roller bearing 30309 7309E 45 100 25 108 130 4000 5000 0.984
taper roller bearing 31309 27309E 45 100 25 95.5 115 4000 5000 0.944
taper roller bearing 32309 7609E 45 100 36 145 188 4000 5000 1.4
taper roller bearing 32910X2 - 50 72 14 22.2 32.8 5000 6300 0.7
taper roller bearing 32910 2007910E 50 72 15 36.8 56 5000 6300 0.181
taper roller bearing 32010X2 2007110X 50 80 19 45.8 66.2 4500 5600 0.31
taper roller bearing 32010 2007110E 50 80 20 61 89 4500 5600 0.366
taper roller bearing 33010 3007110E 50 80 24 76.8 110 4500 5600 0.433
taper roller bearing 33110 3007710E 50 85 26 89.2 125 4300 5300 0.572
taper roller bearing 30210 7210E 50 90 20 73.2 92 4300 5300 0.529
taper roller bearing 32210 7510E 50 90 23 82.8 108 4300 5300 0.626
taper roller bearing 33210 3007210E 50 90 32 112 155 4300 5300 0.825
taper roller bearing 30310 7310E 50 110 27 130 158 3800 4800 1.28
taper roller bearing 31310 27310E 50 110 27 108 128 3800 4800 1.21
taper roller bearing 32310 7610E 50 110 42.5 178 235 3800 4800 1.89
taper roller bearing 32911 2007911E 55 80 17 41.5 66.8 4800 6000 0.262
