40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
Specifications
Brand Name :
UIB, PBQ, ZBY
Model Number :
23120 CCW33 P5
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
100PCS
Price :
negotiable
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
5000pcs per month
Delivery Time :
20 days
Packaging Details :
standard export package, single color box
Bearing weight :
1.12 KG
Boundary size :
40*90*33 MM
Bearing cage :
steel or brass
grease lubricate speed :
6300 (r/min)
oil lubricate speed :
8000 (r/min)
Dynamic load Cr :
105 KN
Static load Cor :
118 KN
Bearing applicant :
universal machine, electric motor
Description

40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing

Product knowledge:

1. The outer ring without guard N0000 model and inner ring without guard NU0000 type, cylindrical roller bearing such large radial load bearing acceptable limit rotational speed is high, not bound shaft or shell axial displacement, cannot accept the axial load.

2. The inner and outer rings are equipped with cylindrical roller bearing with baffle, NJ0000 type and NF0000 bearing can be the axial displacement of the bound shaft or the shell, and can accept the smaller one-way axial load. The NU0000+HJ0000 type, NJ0000+HJ0000 type and the NUP0000 type bearing can tie the axial displacement of the shaft or the shell in the axial clearance field of the imported bearing, and can accept the smaller two-way axial load.

bearing type ISO bearing NO. OLD bearing NO. ID OD WIDTH Cr Cor grease lubricatedx
speed		 oil lubricated
speed		 weight
cylindricall roller bearing (mm) (mm) (mm) (kN) (kN) (r/min) (r/min) (kg)
cylindricall roller bearing NU2308E 32608E 40 90 33 105 118 6300 8000 0.974
cylindricall roller bearing NU2308 32608 40 90 33 105 118 6300 8000 1
cylindricall roller bearing NU2308M 32608H 40 90 33 105 118 6300 8000 1.1
cylindricall roller bearing NU2308EM/P6 E32608EH 40 90 33 105 118 6300 8000 1.15
cylindricall roller bearing NU2308EM/P5 D32608EH 40 90 33 105 118 6300 8000 1.15
cylindricall roller bearing NU2308EM 32608EH 40 90 33 105 118 6300 8000 1.1
cylindricall roller bearing NU2308/C3 7G32608 40 90 33 105 118 6300 8000 1

40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing

40*90*33mm Cylindrical Steel Roller Bearing , High Speed Radial Load Bearing
