Specifications
Brand Name :
UIB
Model Number :
6307 ZZ
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
100PCS
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30000per month
Delivery Time :
25 days
Packaging Details :
industrial package, single UIB color box
Bearing material :
Chrome steel GCR15, AISI 52100
Bearing Precision :
ABEC-1, P0, ABEC-3, P6, P5
Package :
Plastic tube 10 pcs, single color box
Applicant :
agriculture machine, auto wheel bearing
Description

High Speed Anti Friction ABEC 3 Bearings AISI 52100 For Agriculture Machine

I. Product brief introduction:

We using standard chrome steel GCR15, AISI52100 to prepare our rings, G10,G16 grade bearing balls.

Both inner and outer ring groove has to be polished to guarantee bearing movement more fluent and low noise.

Our bearing work life more longer then ordinary bearings, because our polish working time is longer then market normal level.

Conveyor roller had several layers of nylon roller bearing seal protection, sealed performance is good, bearing and seal to reinvent the wheel, open type roller bearing convenient installation themselves according to the actual situation before mastering roller bearing lubrication oil filling quantity.

6307 ZZparameters
Bearing dynamic load Cor 19KN
Bearing static load Cr 33 KN
Bearing weight 0.45 KG
Bearing seal type steel cover, shield type, ZZ 2RZ 2RS

II. Product advantage:

Polished ball groove, super grinding, forged rings.

Competitive price and quite stable quality;

Large stock rings, fast delivery guranteed.

High precision tolerance as per DIN standard;

The dimension accuracy and rotation precision of conveyor roller bearing are based on ISO and JIS scale.

For high-precision and high-speed machines, recommend the use of level 5 or above precision conveyor roller bearings, deep groove ball bearings, angular contact ball or conveyor roller bearings are used in high running accuracy mechanical.

Rigidity, when the conveyor roller bearings and raceway contact surface compression, can produce elastic deformation. Some machines need to minimize elastic deformation.

The conveyor roller bearing is less elastic than the ball bearing roller bearing.

III. Product applicant:

Mainly used in conveyor rollers in normal precision grade.

Higher precision used in engine bearing, motorcycle front wheel, electric motors.

6307 2RS ZZ specification
bearing type ISO bearing NO. OLD bearing NO. ID OD WIDTH Cr Cor grease lubricatedx
speed		 oil lubricated
speed		 weight
(mm) (mm) (mm) (kN) (kN) (r/min) (r/min) (kg)
deep groove ball bearing 6307 307 35 80 21 33.4 19.3 8500 10000 0.457
deep groove ball bearing 6307-Z 60307 35 80 21 33.4 19.2 8000 9500 0.42
deep groove ball bearing 6307-2Z 80307 35 80 21 33.4 19.2 8000 9500 0.42
deep groove ball bearing 6307N 50307 35 80 21 33.4 19.2 8000 9500 0.42
deep groove ball bearing 6307-ZN 150307 35 80 21 33.4 19.2 8000 9500 0.42
