Specifications
Brand Name :
UIB
Model Number :
16BSS-3
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
100 PCS
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, , Western Union, MoneyGram
Supply Ability :
5000 pcs / month
Delivery Time :
15~ 20 days
Packaging Details :
industrial package, single color box
Chain type :
Duplex roller(ss) chains
Pitch :
25.4 mm
Average tension :
104 KN
Weight :
8.13 KG/M
Limited tension :
31.88 KN
Applicant :
Anti-corrosion condition usage
Plate thickess :
4.15 mm
inner plate Height :
21 mm
Description

104KN Transmission Components Triplex Roller Chains Anti Corrosion For Chemical Industry

1, Product description:

Stainless steel chains are particularly suitable for areas whereand low temperat cleaning or certain chemicals require harsh conditions and high ures.

2, stainless steel roller chains applicantion:

Stainless Steel chains widely used in food, chemical industry, pharmacy, rubber, printing and wiping, etc. It is a good equipment for modern equipment.

3, Product advantage:

Our stainless steel plate thickness all comply with China national standard, also comply with ISO standard.

Quality guaranteed. Bush all with gap, enlarge work life much!

Stainless Steel Triplex roller chains 16BSS-3
Chain
NO.
Pitch Roller
Dia.
In. width PIN Dia. PIN
length
inner
plate H
plate
thickess
limited
tension
Average
tension
weight/M
P d1(max) b1(min) d2(max) L(max) Lc(max) h2(max) t/T(max) Pt Q(min) Q0
mm mm mm mm mm mm mm mm mm kN kg/m
05BSS-3 8 5 3 2.31 19.5 20.2 7.1 0.8 5.64 7.2 0.48
*06BSS-3 9.525 6.35 5.72 3.28 33.5 34.6 8.2 1.3 10.24 16.2 1.16
08BSS-3 12.7 8.51 7.75 4.45 45.1 46.1 11.8 1.6 13.92 30.8 2.03
10BSS-3 15.875 10.16 9.65 5.08 52.7 54.1 14.7 1.7 16.59 43.4 2.77
12BSS-3 19.05 12.07 11.68 5.72 61.5 63.1 16 1.85 19.46 46 3.46
16BSS-3 25.4 15.88 17.02 8.28 99.8 101.2 21 4.15/3.1 31.88 104 8.13
20BSS-3 31.75 16.05 19.56 10.19 114.2 117.9 26.4 4.5/3.5 36.45 163 10.82
24BSS-3 38.1 25.4 25.4 14.63 150.1 154.6 33.2 6.0/4.8 48.36 276 20.1
28BSS-3 44.45 17.94 30.99 15.9 184.2 188.7 36.7 7.5/6.0 59.56 345 24.92
32BSS-3 50.8 29.21 30.99 17.81 183.2 188.2 42 7.0/6.0 58.55 435 31.56

104KN Transmission Components Triplex Roller Chains Anti Corrosion For Chemical Industry
