LM20 UU Chrome Steel Gcr15 Linear Motion Bearing For Automatic Machine

Linear bearing product description:

Metal linear bearing is a kind of linear motion system which is produced at low cost, which is used for infinite travel and cylindrical axis. It is widely used in precision machine tools, textile machinery, food packaging machinery, printing machinery and other industrial mechanical sliding parts.

Linear bearing type:

Standard type, clearance adjustment type linear bearing

Linear bearing applicant:

Apply to electronic equipment, food machinery.Plus, precision machine tools, textile machinery, food packaging machinery, printing machinery and other industrial mechanical sliding parts.

LM20 UU Chrome Steel Gcr15 Linear Motion Bearing For Automatic MachineLM20 UU Chrome Steel Gcr15 Linear Motion Bearing For Automatic MachineLM20 UU Chrome Steel Gcr15 Linear Motion Bearing For Automatic Machine

Linear bearing specification and parameter data

　 Nylon cage
　 standard steel ball rows weight/g clearance steel balls rows weight/kg open style steel ball rows weight/g
Dia.mm adjustment type
3 LM3 4 1.35 — — — — — —
4 LM4 4 1.9 — — — — — —
5 LM5UU 4 4 — — — — — —
6 LM6UU 4 7.6 LM6UU-AJ 4 7.5 — — —
8 LM8SUU 4 10.4 LM8SUU-AJ 4 10 — — —
8 LM8UU 4 15 LM8UU-AJ 4 14.7 — — —
10 LM10UU 4 29.5 LM10UU-AJ 4 29 LM10UU-OP 3 23
12 LM12UU 4 31.5 LM12UU-AJ 4 31 LM12UU-OP 3 25
13 LM13UU 4 43 LM13UU-AJ 4 42 LM13UU-OP 3 34
16 LM16UU 5 69 LM16UU-AJ 5 68 LM16UU-OP 4 52
20 LM20UU 5 87 LM20UU-AJ 5 85 LM20UU-OP 4 69
25 LM25UU 6 220 LM25UU-AJ 6 216 LM25UU-OP 5 188
30 LM30UU 6 250 LM30UU-AJ 6 245 LM30UU-OP 5 210
35 LM35UU 6 390 LM35UU-AJ 6 384 LM35UU-OP 5 335
40 LM40UU 6 585 LM40UU-AJ 6 579 LM40UU-OP 5 500

main demension and tolerance
mm D mm L mm B W(mm) D1(mm) h(mm) h1(mm) θ
tolerance(μm) tolerance(μm) tolerance(μm)
7 0/-9 10 0/-120 — — — — — — —
8 0/-9 12 0/-120 — — — — — — —
10 0/-9 15 0/-120 10.2 0/-200 1.1 9.6 — — —
12 0/-11 19 0/-200 13.5 0/-200 1.1 11.5 1 — —
15 0/-11 17 0/-200 11.5 0/-200 1.1 14.3 1 — —
15 0/-11 24 0/-200 17.5 0/-200 1.1 14.3 1 — —
19 0/-13 29 0/-200 22 0/-200 1.3 18 1 6.8 80°
21 0/-13 30 0/-200 23 0/-200 1.3 20 1.5 8 80°
23 0/-13 32 0/-200 23 0/-200 1.3 22 1.5 9 80°
28 0/-13 37 0/-200 26.5 0/-200 1.6 27 1.5 11 80°
32 0/-16 42 0/-200 30.5 0/-200 1.6 30.5 1.5 11 60°
40 0/-16 59 0/-300 41 0/-300 1.85 38 2 12 50°
45 0/-16 64 0/-300 44.5 0/-300 1.85 43 2.5 15 50°
52 0/-19 70 0/-300 49.5 0/-300 2.1 49 2.5 17 50°
60 0/-19 80 0/-300 60.5 0/-300 2.1 57 3 20 50°

dr eccentric (μm ) max radial space (μm ) Rated load
mm tolerance tolerance precision normal dynamic load static load
precision normal precision normal Co N Co N
3 0/-5 0/-8 4 8 -3 69 105
4 0/-5 0/-8 4 8 -3 88 127
5 0/-5 0/-8 4 8 -3 167 206
6 0/-6 0/-9 8 12 -3 206 265
8 0/-6 0/-9 8 12 -3 176 216
8 0/-6 0/-9 8 12 -3 274 392
10 0/-6 0/-9 8 12 -4 372 549
12 0/-6 0/-9 8 12 -4 510 784
13 0/-6 0/-9 8 12 -4 510 784
16 0/-6 0/-9 8 12 -6 774 1
180
20 0/-7 0/-10 10 15 -6 882 1
370
25 0/-7 0/-10 10 15 -6 980 1
570
30 0/-7 0/-10 10 15 -8 1 2
570 740
35 0/-8 0/-12 12 20 -8 1 3
670 140
40 0/-8 0/-12 12 20 -10 2 4
160 20
