Robust 9999m/S 0.1mm Display Ultrasonic Thickness Tester

Specifications

Brand Name :

LANRY

Model Number :

MT150

Place of Origin :

China

MOQ :

1 piece/pieces

Supply Ability :

5000unit/units per week Portable Metallic Pipe Wall Thickness Gauge Meter MT160

Packaging Details :

Ultrasonic Thickness Gauge 32*25*9mm,2.5kg

Product name :

Digital Portable Ultrasonic Thickness Gauge MT150

Suitable material :

metallic and non-metallic

Measure range :

0.75mm to 300mm(Steel)

Accuracy :

±(0.5%Thickness+0.04)mm

Display resolution :

0.1 mm

Description

Digital Portable Ultrasonic Thickness Gauge MT150 Product Description

TG-MT150/160 Ultrasonic Thickness gauge is used for measuring the thickness of materials where access to only one side of the test piece is available for many different materials including steel, cast iron, aluminum, red copper, brass, zinc, quartz glass, polyethylene PVC, gray cast iron, nodular cast iron and other ultrasonic wave well-conductive materials. Dual probe extended your measure range to every possible need in your area. Transducer models are available for special application, including for coarse grain material and high temperature applications. Two-Point Calibration function; Two work modes: Single point mode and Scan mode; Coupling status indicator showing the coupling status;Auto sleep and auto power off function to conserve battery life.

Digital Portable Ultrasonic Thickness Gauge MT150 Features

Digital Portable Ultrasonic Thickness Gauge MT150

Large LCD for easy reading
Suitable for all metallic and non-metallic materials
Easy to operate
Wide measuring range from 0.75mm to 300mm (Steel)
Sound Speed Range up to 9999m/s
Display resolution 0.1 mm
Handheld and robust

Digital Portable Ultrasonic Thickness Gauge MT150 Function

Digital Portable Ultrasonic Thickness Gauge MT150

Applicable to measure the thickness of any hard materials, e.g. steel, cast iron, aluminum, red copper, brass, zinc, quartz glass, polyethylene PVC, gray cast iron, nodular cast iron
Automatic Zero Adjustment
Data Store Function for up to 20 t files (up to 99 values for each file) of stored value
Auto Power Shut Off
Linear compensation circuit for high accuracy (1%H+0.1)
Speed of sound testing (m/s) with 12 storage memory.
2.5 MHz for rough surface measurement

Digital Portable Ultrasonic Thickness Gauge MT150 Speciffication

Used for measuring thickness and corrosion of pressure vessels, chemical equipment, boilers, oil storage tanks, etc. Widely used in industries of petroleum, ship building, and machine manufacturing.

Technical information	MT150	MT160
Display	4.5 digits LCD with EL backlight.
Measuring Range	0.75~300mm (in Steel)
Sound Velocity Range	1000~9999 m/s
Resolution	0.1mm	0.1/0.01mm(selectable)
Accuracy	±(1%Thickness+0.1)mm	±(0.5%Thickness+0.04)mm, depends on materials and conditions
Units	Metric/Imperial unit selectable
Reading type	Four measurements readings per second for single point measurement, and ten per second for Scan Mode
Memory capacity	Memory for up to 20 files (up to 99 values for each file) of stored value
Communication	N/M	RS232 serial port
Setting & Alarm	N/M	Upper and lower limit can be pre-set. It will alarm automatically when the result value exceeding the limit
Power Source	Two “AA” size, 1.5 Volt alkaline batteries. 100 hours typical operating time (EL backlight off)
Outline dimensions	150×74×32 mm
Case	ABS
Weight	245g

Configuration

	No.	Item	Quantity	Remarks
Standard Configuration	1	Main body	1
	2	Transducer	1	Model: N05/90°
	3	Couplant	1
	4	Instrument Case	1
	5	Operating Manual	1
	6	Alkaline battery	2	AA size
Optional Configuration	7	Transducer: N02
	8	Transducer: N07
	9	Transducer: HT5

Appendix A: Transducer Selection

Appendix B: Sound Velocities
