2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
Specifications
Brand Name :
QRsonic
Model Number :
QR-B402
Certification :
CE
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotation
Payment Terms :
T/T, Western Union
Supply Ability :
2000pcs per month
Delivery Time :
3 workdays
Packaging Details :
Packed in carton
Products Name :
Ultrasonic Replacement Converter
Frequency :
20 khz
Output power :
2000 watt
Joint bolt :
1/2-20UNF
Ceramic disc Diameter :
50mm
Capacitance :
11-12nf
Amplitude :
10um
Application :
Ultrasonic plastic welding machine
Description

Supply 20Khz 2000w Ultrasonic Replacement Branson Converter 402 for 8400 Welding Machine

Description:

Replacement Branson 402 Converter .
For use with 182 & 184 V/P 20khz power supplies; also press models 8200 and 8400

Ultrasonic Converters are the core components of many ultrasonic devices such as ultrasonic shearing machines, ultrasonic hot drilling machines, and ultrasonic masking machines. Their main function is to generate ultrasonic waves and convert them into mechanical vibration energy.

Specifications:

Model QR-B402
Frequency 20 khz
Output power 2000 watt
Joint bolt 1/2-20UNF
Ceramic disc Diameter 50mm
Qty of ceramic discs 4pcs
Capacitance 11-12nf
Amplitude 10 um
Application Plastic welding machine

What should I do if I find a problem after ultrasonic welding?


Ultrasonic welding found that the product size is unstable:
1. Increase the welding safety factor (by welding time, pressure, power).
2. Enable the fine adjustment screw (should be controlled to 0.02m/m).
3. Check if the output energy of the ultrasonic upper die is sufficient (increasing the number of segments when not enough).
4. Check if the fixture positioning and product bearing capacity are stable.
5. Modify the ultrasonic waveguide fuse.

Supply 20Khz 2000w Ultrasonic Replacement Branson Converter 402 for 8400 Welding Machine


2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer

2000w Ultrasonic Welding Converter 402 For 8400 Welding Machine , 20 Khz Ultrasonic Transducer
