Specifications
Brand Name :
FUNSONIC
Model Number :
FS2000-8
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 UNIT
Payment Terms :
T/T, Western Union
Supply Ability :
1000 unit per month
Packaging Details :
Packed by Wooden Case
Production Name :
Intelligent Ultrasonic Precision Spraying Machine
Frequency :
20-200Khz (Normally use 60/100/110/120Khz)
Max Power :
1-15w
Continuous Spraying Volume Max :
0.01-50ml/min
Effective Spraying Width :
2-100mm
Spray Uniformity :
<5%
Solution Viscosity :
≤30cps
Input Voltage :
220V±10%/50-60Hz
Description

Textile Fabric Waterproof Ultrasonic Coating


Description:

Textile fabric waterproof ultrasonic coating is used to apply advanced high-performance textile coatings in the manufacturing process. The large-scale textile coatings used include waterproof and oil resistant coatings, antibacterial and anti fouling finishing. Textile fabric waterproof ultrasonic coating sprays a uniform thin film of nano suspension or solution onto wide fabrics used in medical textiles, flooring, carpets, automobiles, or other industrial textile manufacturing applications. Ultrasonic spraying replaces inefficient immersion or rolling methods with uniform thin film ultrasonic textile coatings.


Parameters:

Product TypeIntelligent Ultrasonic Precision Coating Machine Type FS2000-8
Spray Nozzle Operating Frequency20-200KHz (Normally use 60100110120K)
Nozzle Power1-15W
Continuous Spraying Volume Max0.01-50ml/min
Effective Spraying Width2-100mm
Spray Uniformity≥95%
Solution Conversion Rate≥95%
Dry Film Thickness20nm-100μm
Solution Viscosity≤30cps
Temperature Range1-60℃
Atomized Particles (Median Value)10-45μm (distilled water), determined by the frequency of the nozzle
Diversion Pressure Max≤0.15MPA
Input Voltage220V±10%/50-60Hz
Exercise ModeXYZ three-axis, independently programmable
Control ModeFUNSONIC spraying control system, PLC control, 13.3-inch full-color touch screen
Control ContentUltrasonic spraying, liquid supply, heating, ultrasonic dispersion and other systems



Advantages :

1. Modify the existing production line.
2. Accurate, reproducible, and controlled deposition coatings.
3. Very small atomized droplets with uniform particle size form a uniform nano layer film.
4. The unobstructed ultrasonic nozzle reduces maintenance downtime.
5. Significantly reduce the use of spraying materials, water, and energy (up to 80% reduction).
Unlike pressure spraying or immersion methods, soft atomization spraying with minimal rebound provides a very effective coating process.
7. Reduce the release of materials into the atmosphere, minimize overspray, and reduce or eliminate the environmental benefits of wastewater treatment.
