NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
NPN Signal Output 24V Ultrasonic Range Finder Sensor 20 - 350mm Measuring Range
Specifications
Model Number :
AU0009-001
Place of Origin :
Guangdong, China
Brand Name :
AUDIOWELL
MOQ :
1000 pieces
Price :
$2.00 - $15.00/pieces
Series :
Ultrasonic Sensor
Features :
20~350mm Measuring Range
Mounting Type :
inlaid
Description :
20~350mm Measuring Range Ultrasonic Rangefinder, Ultrasonic Rangefinder
Type :
Ultrasonic Sensor
Usage :
Production Line Testing
Theory :
ultrasonic
Output :
NPN Signal, NPN output
Frequency :
60 KHz
Measuring distance :
2~35 cm
Accuracy :
≤±1 cm
Operating voltage(rated) :
12 V~30 V(rated voltage 24 V)
Working temperature :
-10℃~+50℃
Protection level :
IP65
Description

AUDIOWELL 20~350mm Measuring Range NPN Signal Output 24V Ultrasonic Rangefinder for Production Line Testing

Product Details

Item
Standard
Frequency
60±1.0 KHz
Measuring Distance
2~35 cm
Accuracy
≤±1 cm
Output
NPN output
Operating Voltage(rated)
12 V~30 V (Rated Voltage 24 V)
Working Temperature
-10 ℃~+50 ℃
Protection Class
IP65
