1.2 Footcandles Magnetic Particle Testing Headlight With 1 UV LED Light Source TMUV-40T
1.2 Footcandles Magnetic Particle Testing Headlight With 1 UV LED Light Source TMUV-40T
1.2 Footcandles Magnetic Particle Testing Headlight With 1 UV LED Light Source TMUV-40T
1.2 Footcandles Magnetic Particle Testing Headlight With 1 UV LED Light Source TMUV-40T
1.2 Footcandles Magnetic Particle Testing Headlight With 1 UV LED Light Source TMUV-40T
1.2 Footcandles Magnetic Particle Testing Headlight With 1 UV LED Light Source TMUV-40T
1.2 Footcandles Magnetic Particle Testing Headlight With 1 UV LED Light Source TMUV-40T
1.2 Footcandles Magnetic Particle Testing Headlight With 1 UV LED Light Source TMUV-40T
Specifications
Brand Name :
TMTECK
Model Number :
TMUV-40T
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
Western Union, T/T,PayPal
Supply Ability :
100pcs/month
Delivery Time :
5-8 days
Packaging Details :
carton
Wavelength :
365±5nm
Lamp Style :
Headlight
UV-A Coverage Area at 15 in (38cm) :
1.5 In (4 Cm) Diameter (min 10,000µW/cm²)
IP Grade :
IP65 (Dust And Water Jetting Proof)
Visible Light :
1.2 Foot-candles (13 Lux)
UV Intensity at 15 in (38cm) :
40,000 µW/cm²(max)
Filter Glass :
Built-in Antioxidant Blak Light Filters
Light Source :
1 UV LED
Description

Product Description:

TMTECK headlights are small-sized, lightweight and designed to release the test
engineer's hands during inspection. It is compliant with ASTM UV-A intensity and
wavelength specifications for LPT and MPT. It is widely used in nondestructive testing
(NDT), forensic inspection, quality control, fluorescent leak detection, industrial inspection,
and so on.

Features:

TMUV40T: 1.5 in (4cm) diameter coverage area at 15 inches (38cm), with a max UV
intensity of 40,000μW/cm² and min UV intensity of 10,000μW/cm².
TMUV100T: 4 in (10cm) diameter coverage area at 15 inches (38cm), with a max UV
intensity of 15,000μW/cm² and min UV intensity of 1,000μW/cm².
Instant-on operation; lamp reaches full intensity immediately!
Every lamp is mounted with an antioxidant black light filter glass.
The headlights can be adjusted in different angles.
It is small size, light weight and cordless. Use it anywhere.

Technical Parameters:

Visible Light 1.2 Foot-candles (13 Lux)
Light Source 1 UV LED Headlight
IP Grade IP65 (Dust And Water Jetting Proof)
Wavelength 365±5nm
Power Consumption <3W
UV Intensity at 15 in (38cm) 40,000 µW/cm² (max)
Lamp Style UV LED Inspection Flashlight
Filter Glass Built-in Antioxidant Black Light Filters
UV-A Coverage Area at 15 in (38cm) 1.5 In (4 Cm) Diameter (min 10,000 µW/cm²)
Power Supply
One Rechargeable 3.7V 3000mAh Li-ion Battery
Running Time
Approximately 5 hours
Charge Time
Approximately 4 hours
Battery Charger
AC 100-240V; DC output 4.2V 1A
Lamp Head Diameter
48mm
Lamp Length
59mm
Weight (With Battery)
 238g
