20KHZ Ultrasonic Filter Seam & sealing machine by ultrasonic rotary horn

Parameter

RPS-SONIC are the only supply of the 20khz ultrasonic rotary horn. For this 20Khz ultrasonic rotary horn, we have updated the design with one-piece horn, there will be no connect screw for the rotray horn part, so that we can Minimize losses. And the ultrasonic rotary horn width can be 25mm in max, the welding width can be 25mm in max, the cutting thickness can be 8mm in max. Till now, it is the Radial ultrasonic welding equipment with largest amplitude. This filter welding machine has been specially designed to weld pleated filter elements in thermoplastic fabric or weld pleated filter elements in cellulose or non synthetic fabric with an adhesive film.Ultrasonic bonding is accomplished by channelling highfrequency vibrations to the fabric. As synthetic or nonwoven material passes between the ultrasonic horn or sonotrode and the pattern wheel or roller, the vibrations are directed into the fabric where they create a rapid heat build-up. This heat causes the material’s synthetic fibresto melt and fuse, creating bonded seams that will not fray or unravel and provide a full barrier.

RPS-SONIC Offers the Most Complete Line of Ultrasonic Machinery for Filtration Assembly Applications

“Ultrasonics is a dependable, well-established, environmentally-friendly process. And rps-sonic has bonding machines for ultrasonic assembly of practically any type of filter. These include filtration products for the airline, automotive, food, paper, pharmaceutical, air and water filtration, liquid absorption, petroleum, and agricultural fields.

filtration assemblers can confidently look to rps-sonic for the machinery best suited to their specific needs, whether it is a stand-alone unit or incorporated into their production line.
Fast, Dependable Bonds in One, Easy Step

Suitable material :
Fabrics of synthetic composition over 65%, polyester, nylon, TC, sponge, non-woven fiber , satin, Thermo plastic films. And other synthetic fibre material

Why RPS-SONIC:

The right one is from RPS-SONIC, RPS-SONIC will supply you the machine with best quality in every details.
