30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine
30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine
30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine
30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine
30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine
30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine
Specifications
Brand Name :
Altrasonic
Model Number :
HS-N30
Certification :
BV
Place of Origin :
China
MOQ :
1 unit
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
1000 units per year
Delivery Time :
7 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Product Name :
Industrial Humidification Ultrasonic Nozzle Spray For Granulating , Mixing Liquid
Frequency :
30Khz
Atomization Volume :
70L/H
Average Particle Diameter of Fog :
39um
Power :
100W
Atomization Head Structure :
Horn
Description

30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine

Description:


Ultrasonic spray (FOG) is to use the energy of ultrasonic water or liquid scattered, forming several microns to 100 microns in size of particles, used for air humidifying, granulating, mixing liquid, promote chemical reactions, spraying, molten metal powder etc.By breaking apart aggloomerated particles as they travel down the nozzle body due to continuous ultrasonic vibrations along the length of nozzle, resulting in the most effective use of functional particles.

Applications:

Atomization humidification, chemical mixing, production, spray drying granulation, paint spraying, metal milling and so on. The advantage is that it can atomize various kinds of liquid and it has Large atomizing volume, energy-saving, environmental protection. It has no plug, no abrasion.

Specifications:

Model

HS-N60

HS-N50A

HS-N50B

HS-N50C

HS-N40

HS-N30

HS-N20

HS-N15

Frequency

60KHz

50KHz

50KHz

50KHz

40KHz

30KHz

20 KHz

15 KHz

Atomization Volume

0.5L/H

2 L/H

2 L/H

2 L/H

10 L/H

70 L/H

100 L/H

150 L/H

Average Particle Diameter of Fog

20um

28um

28um

28um

32um

39um

51um

62um

Power Consumption

0.01 Degrees/Kg

0.001 Degrees/Kg

Atomization Head Structure

Cylindrical

Horn

Power

30W

30 W

30 W

30 W

60 W

100 W

300 W

500 W

The Application of Atomizing Media

Ordinary water, a variety of liquid substances, chemical liquid,

a variety of oil mucus, metal melt and so on

Competitive Advantage:

★ A major breakthrough in spray technology, you can spray a variety of liquids.
★ Low power consumption, the fog of great energy saving.
★ No plug, no abrasion, no noise, no pressure, no moving parts.
★ Can be any combination to meet the requirements of the spray volume.
★ The use of high-performance titanium and stainless steel.

30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine

30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine30Khz Ultrasonic Nebulizer For Mixing Liquid , Industrial Nebulizers Machine
