Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool
Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool
Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool
Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool
Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool
Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool
Specifications
Brand Name :
Altrasonic
Model Number :
HSW35
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
2000pcs per month
Delivery Time :
Within 7 weekdays after receipt total amount
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Item No. :
HSW35
Frequency :
35kHz
Power :
1000W
Horn :
≤10mm
Housing Diameter :
44mm
Color :
Blue and Silver
Warranty :
1 year
Shipping :
TNT UPS DHL FEDEX
Description

Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool

Item No. HSW20 HSW30 HSW35 HSW40 HSW60
Frequency 20kHz 30kHz 35kHz 40kHz 60kHz
Power 1000W 1200W 1000W 500W 300W-500W
Horn ≤12mm ≤10mm ≤10mm ≤10mm ≤10mm
Housing Diameter 44mm 44mm 44mm 44mm 44mm
Weight of Welder 1.0kg 1.0kg 1.0kg 1.0kg 1.0kg

Ultrasonic Staking Assembly 35kHz 1000W for Automated Machine Tool

Description:

The basic principle of ultrasonic assembly is to convert the electrical energy into high-frequency mechanical vibration by expanding and contracting the converter, usually lead zirconate titanate, at the same frequency.This vibration is amplified by a booster and transferred to the workpiece through a shaped tool, or horn, in the form of reciprocating longitudinal motion. Parts being assembled are clamped together under moderate pressure, at which point ultrasonic vibrations force the parts to impact against each other at a preset frequency creating a molecular bond equal to or above the material strength of the parts.
Infinite and accurate combinations of weld time, distance and energy, established through a microprocessor, provide repeatable control of the process, and lend to the full automation of the assembly. Statistical process control and reporting are also possible with some models.

Specification:

Item No. HSW20 HSW30 HSW35 HSW40 HSW60
Frequency 20kHz 30kHz 35kHz 40kHz 60kHz
Power 1000W 1200W 1000W 500W 300W-500W
Horn ≤12mm ≤10mm ≤10mm ≤10mm ≤10mm
Housing Diameter 44mm 44mm 44mm 44mm 44mm
Weight of Welder 1.0kg 1.0kg 1.0kg 1.0kg 1.0kg

Advantage:

• No welding sparks, environmental safety
• Low power consumption, good effect, small noise and small size.
• Simple operation
• Welding joints are highly sealed and the welding process is stable
• Fast, efficient and short welding time, without any flux, gas or solder
Application:
Appliance Fixtures, hardware, and enclosure assembly, welding of components.
Automotive Parts and body components, instrument panels, headlight assemblies, under hood assemblies.
Cosmetic Assembly of compacts and other containers, sealing tubes, packaging.
Electronic/Electrical

Component, connector cable and wire harness assemblies, enclosure cases and instrument faces, audio/video cassette and cartridge, switch assemblies.
Food

Sealing of pouches, tray containers and tubes; sealing microwavable containers; product packaging.
Hardware

Product assembly and blister pack packaging.
Health Care

Product containers and accessories.

Types of ultrasonic assembly:

Ultrasonic vibratory energy is used in several distinct assembly and finishing techniques such as:

Welding : The process of generating melt at the mating surfaces of two thermoplastic parts. When ultrasonic vibrations stop, the molten material solidifies and a weld is achieved. The resultant joint strength approaches that of the parent material; with proper part and joint design, hermetic seals are possible. Ultrasonic welding allows fast, clean assembly without the use of consumables.

Staking : The process of melting and reforming a thermoplastic stud to mechanically lock a dissimilar material in place. Short cycle times, tight assemblies, good appearance of final assembly, and elimination of consumables are possible with this technique.

Spot Welding : An assembly technique for joining two thermoplastic components at localised points without the necessity for preformed holes or an energy director. Spot welding produces a strong structural weld and is particularly suitable for large parts, sheets of extruded or cast thermoplastic, and parts with complicated geometry and hard-to-reach joining surfaces.

Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool

Long Life Ultrasonic Plastic Riveting Machine Staking Assembly For Automated Machine Tool
