Specifications
Brand Name :
KnMTech
Model Number :
KM-NQD3015
Place of Origin :
China
MOQ :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500sets per month
Delivery Time :
3-7 work days
Packaging Details :
paper/wood carton
Price :
Negotiation
Product Name :
30KHz Ultrasonic Welding Generator
Frequency :
30KHz
Output power :
0-1500W
Power supply :
AC220V 50Hz
Power fluctuation :
≤ 5%
After-sales service provided :
Online support,Video technical support
Warranty :
1 Year
Usage :
Plastic Welding,Ultrasonic Plasitc Welder for ABS PP PE PC Material,ultrasonic welding
Description

30khz 1500w Horizontal Type Digital Ultrasonic Welding Generator For Plastic Welding

This is the horizontal type ultrasonic welding generator with the new look and digital circuit, which has three working modes, you can adjust the setting according to different products.

Working Principle:

When ultrasonic acts on the two thermoplastic plastics’ surface, it will produce tens of thousands of times of high-frequency vibration per second. This kind of high-frequency vibration reaches a certain amplitude , and transmits ultrasonic energy to the welding area through welding parts. As the welding area is the interface of two welding surfaces, the sound resistance is large, so local high temperature will be generated.

Because of the poor thermal conductivity of plastic, for a time can not be distributed in a timely manner, concentrated in the welding area, resulting in the two plastic contact surface quickly melting, plus a certain pressure, so that the two plastic parts can be welded together.

Technical parameters:

Product Name 1500W Ultrasonic Welding Generator
Frequency 30kHz
Trigger mode delay
Power 1500W
Steady output 200-240VAC
Welding modes time, energy and grounding
4-core 32-bit processor
Segmented amplitude function is available
Welding amplitude 10-100% adjustable (1% accuracy)

Features:

1. Two-inch button PLC display

2. Mold impedance analysis + protection

3. 485 communication port

4. Real time frequency automatic tracking function

5. Amplitude compensation function

6. Overload protection

7. Transducer voltage protection

Application:

Digital Horizontal Ultrasonic Welding Generator 30khz 1500W For Plastic Welding

FAQ:

1.What is your lead time?
It depends on customer's requirement and quality.

2.How do you guarantee your production quality?
We take delivery test with our professional QC team before shipment.
3.What countries have you exported?
Our business expanded to all over the world,and our main markets are North American,East Europe,UK,Span,German,South Asia,South Korea ,Poland,etc.

Detailed Photos:

Digital Horizontal Ultrasonic Welding Generator 30khz 1500W For Plastic Welding

Warehouse:

Digital Horizontal Ultrasonic Welding Generator 30khz 1500W For Plastic Welding

CE:

Digital Horizontal Ultrasonic Welding Generator 30khz 1500W For Plastic Welding
