PLC Control Raise Boring Rig 3200 Mm Propel Distance With Air Conditioner
PLC Control Raise Boring Rig 3200 Mm Propel Distance With Air Conditioner
Specifications
Brand Name :
tongguan
Model Number :
TL-100
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5 sets per month
Delivery Time :
35-45days
Packaging Details :
Standard
Machinery :
Open Pit Mining
Type :
Crawler
Drilling Diameter :
100-165mm
Drilling Depth :
30 m
Propel Distance :
3200 mm
Max Propel Speed :
0.45 m/s
Description

Opencast Drilling Rig Crawler Chassis Revolving Platform Raise Boring TL-100

1. Drawing

PLC Control Raise Boring Rig 3200 Mm Propel Distance With Air Conditioner

2. Main Technical Parameters

No. Name Specification Remark
1 Drill parameter Drilling diameter mm φ100～φ165
Drilling depth m 30
Drilling pitch angle　° -10～30 Take the vertical plane as the benchmark
Drill stem diameter mm φ76
Drill stem length m 3or 1.5
Deflection angle ° -30～30 Take the vertical plane as the benchmark
2 Propulsive parameter Advance stroke mm 3200
Propulsion Kg 0～2000 Continuously adjustable
Elevating power Kg 0～2000 Continuously adjustable
Max. propulsive speed m/s 0.45
Compensation stroke mm 1000
3 Platform rotation Rotating speed r/min 0.5　
4 Walking parameter Max. tractive force KN 54
Driving mode Hydraulic crawler
Travelling speed Fast gear 1.9Km/h
Slow gear 0.6Km/h
gradeability 35°
5 Working air pressure Output pressure MPa 1.25
6 Rotary head speed Rotating speed r/min 38
Forward torque N.m 1170
Reverse torque N.m 1850
7 Parameters Engine power KW 58
Control mode PL Control
Dimensions mm 4800X2335X2680 Length×Width×Height
Min. ground clearance mm 330
Revolving platform ground clearance mm 800
Track shoe width mm 450
Total width of the track mm 2310
Unilateral track length mm 6300
Revolving platform width mm 2150
Total weight Kg 8800

3. Product Superiority

● Safe Reliability:

1. Advanced hydraulic integrated technology greatly simplified hydraulic pipeline structure and improved hydraulic system realiablity.

2. Advanced connecting and removing rods device and automatic anti-jamming system to ensure efficient operation of the rig.

●Power Driving Mode:

Driven by diesel engine, with crawler chassis walking system, makes the machine with characteristics of large traction, strong climbing ability, none-slip on muddy road and good trafficability

● Drilling Adaption:

1. Open-pit mining, with complete rig shifting and positioning mechanism, meeting the requirements of slope holes in all directions

2. Parameter can be conveniently stepless-controlled based on actualconditions and drilling depth. It can greatly improve driving power ,stability andanti-overload ability of main working mechanism such as rotation andpropelling, etc.

● Control Performance:

1. Drilling and positioning operation can be completed on the mobile console, which can realize long-distance and multi-directional operation.

2. Advanced PLC control system effectively realized intelligentized functions.

3. Wider-view cab with air-conditioner, harmonious man-machine relationship and excellent working environment.
