ISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper Truck
ISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper Truck
ISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper Truck
ISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper Truck
ISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper Truck
ISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper Truck
Specifications
Brand Name :
Beijun
Model Number :
UQ-25
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1
Price :
USD 85000-90000 Set
Payment Terms :
L/C, T/T
Supply Ability :
1000 Set/Sets per Month
Delivery Time :
7 days
Packaging Details :
Customized packaging
Engine Model :
Yuchai YC6L340-33
Engine Power :
243KW
Transmission Model :
FASITE RT11509C
Drive Mode :
6x4
Dimension of Bottom Spring Plate :
"Front 90*16 Rear 90*24
Cabin :
Closed Cabin with A/C
Type of Bucket :
Right Angle Type
Loading Capacity :
25 Tons
Cooling sytem :
Standard Water Cooling System
Description

Product Features of Heavy Duty Mining Underground 25 Ton Dump Truck Tipper Truck For Sale

The Beijun underground tunnel dump truck is designed for excellent trafficability, featuring a compact structure and small turning radius that allow it to easily navigate narrow spaces inside the roadway ramp. This makes it a reliable and flexible option for mining companies operating in confined underground areas.

Safety is a top priority for the Beijun truck, which is equipped with improved lamps and electrical components, waterproofing and moisture-proofing capabilities, and dedicated anti-slip tires. These features enable the truck to overcome obstacles and maintain high safety standards, even in the challenging underground environment.

The Beijun underground tunnel dump truck's powerful engine, with large torque, excellent grade, and starting performances, enables it to easily handle heavy loads and steep inclines. This improves efficiency and productivity, allowing mining companies to optimize their operations.

The truck's scientific design and configuration, based on the mining vehicle design concept, ensures that it has a strong bearing capacity, 1.5 times that of an ordinary road vehicle. This makes it a reliable and cost-effective choice for transporting heavy loads in underground mining operations. Furthermore, the truck's rugged construction, including its lifting mechanism, cargo compartment, suspension frame, and vehicle frame, enhance its durability and reliability in the harsh underground environment. Additionally, the truck's comfortable cabin and easy-to-use controls provide a pleasant and efficient working experience for operators, increasing their productivity and job satisfaction.

Product parameters of Heavy Duty Mining Underground 25 Ton Dump Truck Tipper Truck For Sale

Model UQ-25
Engine Model Yuchai YC6L340-33
Engine Power 243KW
Total Dimension 7900x2420x2720mm
Transmission Model FASITE RT11509C
Transmission Gear 10 Forward Gear, 2Back Gear,Rear High Speed Controller
Drive Mode 6x4
Front Axle Model Styer Axle
Rear Axle Model Styer Axle
Tire Model 1100R20 Radial steel tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 11 PCS, Rear 12 PCS
Dimension of Bottom Spring Plate Front 90*16
Rear 90*24
Size of the Bucket:Length×width×height 5000x2300x1200mm
Type of Bucket Right Angle Type
Thickness of Bucket Steel Plate bottom 10mm side 8mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Closed Cabin with A/C
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 25 Tons

ISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper TruckISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper TruckISO High Safety Heavy Duty Dump Truck Underground 25 Ton Tipper Truck
