UQ-12 Underground Mining Truck YUNEI 4102 With Turbocharge Engine For Heavy Duty Transportation
UQ-12 Underground Mining Truck YUNEI 4102 With Turbocharge Engine For Heavy Duty Transportation
UQ-12 Underground Mining Truck YUNEI 4102 With Turbocharge Engine For Heavy Duty Transportation
UQ-12 Underground Mining Truck YUNEI 4102 With Turbocharge Engine For Heavy Duty Transportation
UQ-12 Underground Mining Truck YUNEI 4102 With Turbocharge Engine For Heavy Duty Transportation
UQ-12 Underground Mining Truck YUNEI 4102 With Turbocharge Engine For Heavy Duty Transportation
UQ-12 Underground Mining Truck YUNEI 4102 With Turbocharge Engine For Heavy Duty Transportation
UQ-12 Underground Mining Truck YUNEI 4102 With Turbocharge Engine For Heavy Duty Transportation
Specifications
Brand Name :
Beijun
Model Number :
UQ-12
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
1000 Set/Sets per Month
Delivery Time :
8 - 18 days
Packaging Details :
Customized packaging
Engine Model :
YUNEI 4102 with Turbocharge
Engine Power :
81KW/110HP
Transmission Model :
Wanliyang 545
Drive wheel :
4x2
Dimension of Bottom Spring Plate :
Length 70mm, Width 12mm
Color :
Customer's Request
Capacity (load) :
1 - 12t
Type :
Dumping Truck
Description

Product parameters of 12 tons Underground Mining Truck

Mining car - a narrow gauge railway transport vehicle used in mines to transport loose materials such as coal, ore, and waste rock, generally requiring locomotives or winches for traction. Mining cars are divided into five categories based on their structure and unloading methods: fixed mining cars (material cars, flatbed cars), tipping bucket mining cars, single-sided curved rail side unloading mining cars, bottom (side) unloading mining cars, and shuttle mining car basic knowledge training. Mining cars can be loaded with ore gates (or loaders). In the 1970s, China developed bucket type transfer trains, which consist of a bucket car, a lifting platform, and a train of mining cars. After the bucket car is filled with material, it is lifted by the lifting platform and moves along the side of the mining car, gradually transferring it to each mining car, improving the transportation speed and achieving continuous loading of the mining car. The bucket type load train has a simple structure and a small turning radius, and can be modified using the original standard mining car.

Model UQ-12
Engine Model YUCHAI 4102 with Turbocharge
Engine Power 81KW/110HP
Total Dimension 5000*2000*1700mm
Transmission Model Wanliyang 545
Transmission Gear 5 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x2
Front Axle Model 1098
Rear Axle Model 1098
Tire Model 825-16 Radial steel tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 10 PCS, Rear 10 PCS, Spare 6PCS
Dimension of Bottom Spring Plate Length 70mm, Width 10mm
Size of the Bucket:Length×width×height 3400mm*2000mm*700mm
Type of Bucket U-type
Thickness of Bucket Steel Plate bottom 8mm side 6mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 12 Tons
