Software Automatic Metal Charpy Pendulum Impact Tester
Software Automatic Metal Charpy Pendulum Impact Tester
Specifications
Brand Name :
Pride
Model Number :
CH/IMP-300A
Place of Origin :
China
MOQ :
1
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Delivery Time :
10-15 work days
Packaging Details :
Wooden case
impact energy :
150J, 300J, 250J, 500J
Display :
Microcomputer
Round angle jaw :
R1-1.5mm
impact speed :
5.2m/s 5.4 m/s
power supply :
380V/50Hz/5A
Speciment specification :
10×10×55mm
Description

Software Automatic Metal Charpy Pendulum Impact Tester

The impact testing machine is controlled automatically,it can realized operation of rising

pendulum→sending speciment→positioning→second rising pendulum etc,have high operation efficiency and high testing accuracy.The testing machine is suitable to be used in laboratories which make consecutive impact tests or the metallurgy and machine manufacturing sectors which are involved with a large amount of impact tests.

Model CH/IMP-300A CH/IMP-500A
impact energy 150J,300J 250J,500J
Display type Microcomputer display
Pre-rising angle of pendulum 150°
The distance between the pendulum shaft and impact point 750mm 800mm
impact speed 5.2m/s 5.4 m/s
Speciment bearer span 40mm
Round angle of the jaw R1-1.5mm
Round angle of impact cutting edge R2-2.5mm,R8mm
Accuracy of angle 0.1° 0.1°
Speciment specification 10×10×55mm
Speciment box capacity 10PCS
Sending sample centering type automatically
power supply 380V/50Hz/5A
