Automatic Digital Hardness Tester For Brinell Rockwell Vickers Scale Hardness Testing Machine
Automatic Digital Hardness Tester For Brinell Rockwell Vickers Scale Hardness Testing Machine
Specifications
Brand Name :
Pride
Model Number :
UHT-900D
Place of Origin :
China
MOQ :
1pc
Price :
Negotiate
Payment Terms :
T/T, Western Union, MoneyGram,Paypal,Payonner
Supply Ability :
100pcs
Delivery Time :
20-25 days
Packaging Details :
Wooden Case
Type :
Universal
Calibrating :
Standard Hardness Test Blocks
Packing :
Wooden Case
Resolution :
0.1HR
HS Code :
9024102000
Warranty :
1 Year
Description

Automatic Digital Hardness Tester For Brinell Rockwell Vickers Scale Hardness Testing Machine

Features

● UHT-900D is a universal hardness testing instrument for the measurement of Brinell, Rockwell and Vickers scale.
● Equip 7-testing-foce and 5-indenter, it is universal to measure a most of metal material.
● Dwell time from 2 to 60S can be setup by the “time key” inside the LCD panel, it is much convenient than the setup on the manual hardness tester.
● Loading ,dwell and unloading is driven by electronic motor automatically , doesn’t need the operator to handle it, it eliminates the human operating error maximum.
● Doesn’t need the operator to read and check the hardness scale table ,it will compute and display the testing result once press the key of digital length sensor.

Technical specifications:

Model No UHT-900D
Rockwell Scales HRA, HRB, HRC
Rockwell Testing Force 60Kgf(588.4N),100Kgf(980.7N),150Kgf(1471N)
Brinell Scales HBW1/30,HBW2.5/62.5,HBW10/100,HBW2.5/187.5
Brinell Testing Force 31.25Kgf(306.5N),62.5Kgf(612.9N,187.5Kgf(1839N)
Vickers Scales HV 30,HV100
Vickers Testing Force 30Kgf(294.2N),100Kgf(980.7N)
Rockwell Hardness Indication Digital LCD display
Rockwell Resolution 0.1HR
Loading Control Automatic
Data Output RS 232/Printer
Magnification of Microscope Brinell:37.5x; Viceers:75x
Dwell Time 2~60s
Max. Height Of Specimen Rockwell:170mm; Brinell, Vickers:140mm
Instrument Throat 165mm
Dimension(LxWxH) 520 x215 x700mm
Packing Dimension 630 x440 x960mm
Gross/Net Weight 120Kg/90Kg
Execution Standard EN-ISO 6508 , ASTME-18

Standard accesory:

Hardness Block (57-70)HRC

1SET

 Ø5mm Brinell Ball Indenter 1PC Mini-Printer 1PC
Hardness Block (20-33)HRC 1PC Rockwell Cone Diamond Indenter 1PC 2.5x Brinell Objective 1PC
Hardness Block (85-100)HRB 1PC Vickers Indenter 1PC 5x Vickers Objective 1PC
Vickers Hardness Block HV 30 1PC Ø 150mm Flat Anvil 1PC Power Cable 1PC
HBW2.5/187.5 Hardness Block 1PC Ø 55mm V-shape Anvil 1PC Accessories Box 1PC
Ø1.588mm Rockwell Ball Indenter 1PC Ø 55mm Flat Anvil 1PC Instrument Manual 1PC
Ø2.5mm Brinell Ball Indenter 1PC 15x analogue Eyepiece 1PC
