SUS-304 Blue Laboratory Environment Climatic Aging Testing Machine Xenon Lamp Weather Resistance Test Chamber
SUS-304 Blue Laboratory Environment Climatic Aging Testing Machine Xenon Lamp Weather Resistance Test Chamber
SUS-304 Blue Laboratory Environment Climatic Aging Testing Machine Xenon Lamp Weather Resistance Test Chamber
SUS-304 Blue Laboratory Environment Climatic Aging Testing Machine Xenon Lamp Weather Resistance Test Chamber
SUS-304 Blue Laboratory Environment Climatic Aging Testing Machine Xenon Lamp Weather Resistance Test Chamber
SUS-304 Blue Laboratory Environment Climatic Aging Testing Machine Xenon Lamp Weather Resistance Test Chamber
Specifications
Brand Name :
KINSGEO
Model Number :
KJ-2093
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD/6800/SET
Payment Terms :
T/T
Supply Ability :
60Sets/month
Delivery Time :
15 work days
Power :
6.5KW
Inner size(cm):D×W×H :
50×60×50
Humidity range :
65～98％R.H(adjustable)
Rain falling time :
0～9999min (adjustable)
Rain falling period :
1～240minutes，interval（break）,adjustable
Xenon lamp total power :
1.8KW（lifetime：1600hours）
Time Controller :
Imported programmable time computer integrated controller
Accuracy range :
temperature ±0.1℃,humidity±1％R.H，indicate accuracy：temperature,±0.1℃,humidity,±1％R.H
Temperature controller :
Imported microcomputer temperature humidity integration controller
Voltage power :
AC380V±10％ 50±0.5Hz 3 phase 5 lines
Testing standards :
GB/T2423.24-1995 GB/T16422.2 GB9344 GB/T1865-97 ASTM G 155-04a
Safeguard protection :
leakage,short circuit,over temperature,short of water,motor overheating,over-current protection,Backup data for power fail
Warranty :
1 Year
Description

Laboratory Environment Climatic Aging Testing Machine Xenon Lamp Weather Resistance Test Chamber

Chamber Inner Size and Structure:

Inner size(cm):D×W×H 50×60×50
Power 6.5KW
Temperature range Temperature range
Humidity range 65～98％R.H(adjustable)
Rain falling time 0～9999min (adjustable)
Rain falling period 1～240minutes,interval(break),adjustable
Spectral wavelength 290nm～800nm
Xenon lamp total power 1.8KW(lifetime:1600hours)
Time Controller Imported programmable time computer integrated controller
Accuracy range temperature ±0.1℃,humidity±1％R.H,indicate accuracy:temperature,±0.1℃,humidity,±1％R.H
Temperature Humidity Sensor PTR Platinum Resistance,PT100Ω/MV
Heating system autonomous system,nichrome electric heating heater
Humidification System isolated type,SUS steel surface evaporative humidifier.
Blackboard temperature thermometal blackboard thermometal.
Temperature controller Imported microcomputer temperature humidity integration controller
cyclic system low noise,air-condition type motor, multiple-pin Centrifugal rotor.
Outside chamber material SUS304 stainless steel.
Inner chamber material SUS304 stainless steel plate
Sample shelf material SUS304 stainless steel plate
Doorframe heat insulation good heat and cold resistance,aging Silicone rubber door and sealing strips.
Standard configuration non-browning glass observing window 1pcs,xenon lamp 1pcs
Safeguard protection leakage,short circuit,over temperature,short of water,motor overheating,over-current protection,Backup data for power fail
Voltage power AC380V±10％ 50±0.5Hz 3 phase 5 lines
Using temperature 5℃～＋30℃≤85％R.H
Testing standards GB/T2423.24-1995 GB/T16422.2 GB9344 GB/T1865-97 ASTM G 155-04a

Chamber structure:

1.Outside bile uses high quality (t=1mm)SUS304 steel plate numerically-controlled machine tool to process,outside hull spray molding treatment,make chamber more bright and clean.

2.high density glass cellucotton,insulation thickness is 80mm.

3.Use long axis fan motor,heat and cold resistance,stainless steel siroco fan,to make sure strength convection and vertical diffusion cycle.

4.Between door and chamber,use double-deck thermostability sealing strips,to make sure testing area is airtight.

5.Use no-retroaction doorknob,easy operation.

6.In the bottom of chamber,use high quality stationary type PU running wheel.

7.Observing window uses multilayer hollow toughened glass.

Cooling system:

1.Compressor uses France TAIKANG whole sealing compressor.

2.Cooling system uses Unit or binary low temperature return circuit system.

3.US “AIGLE” drying and filtering device,Taiwan AIRMENDER oil separator,Italy Castel solenoid valve.

Product function:

Full spectrum xenon lamp

Various selective filtration system.

Water spray function.

Relative humidity controlling.

Testing chamber air temperature controlling system.

Irregular shape sample supporting structure.

Superior Xenon arc lamp.

Xenon lamp lifelong is decided by the illumination level of radiation intensity,the lifelong is about 1600 hours,it's easy to change the lamp.
