3U 2k/3kva 48v LCD DC to AC pure Sine Wave rack mount Uninterrupted Power Supply UPS
HPR series Rack mount ups1-20KVA
Model:HPR1101B(H)/HPR1102H/HPR1103H/HPR1106H/HPR1110H/HPR3110H/HPR3115H/HPR3120H
UPS power range: 1KVA~20KVA
Features:
1.6KVA/10KVA supports N+1 reliable parallel redundancy technology
2. Rack mount type ups height:1-3KVA 2U, 6-10KVA 3U, 15/20kva 6U
3.DSP technology guarantees high performance 4.Optional output power factor 0.8/0.9/1
5.ECO mode for energy saving
6.Emergency power off function (EPO)
7.Built-in over voltage cut-off protection and surge immunity for full-time protection
8.Low input THDi to reduce power system pollution.
Application:
1 ) Professional and IT equipment,small computer room
2) Servers and networking devices
3) CAD/Graphic workstations
4) Control system
5) Medical, electricity, defense, petrochemical,bank,transport, etc.
Parameter:
Model | HPR1101B | HPR1101H | HPR1102H | HPR1103H | |
Phase | Single phase and earth ground | ||||
Power ratting | 1000VA/800W | 1000VA/800W | 2000VA/1600W | 3000VA/2400W | |
INPUT | |||||
Voltage range | 100-300VAC @ 50% load or 160-280VAC @ 100% load | ||||
Frequency Range | 50Hz/60Hz (auto sensing) | ||||
Frequency Range | ≧0.99 @ 100% load | ||||
OUTPUT | |||||
Norminal voltage | 200/208220/230/240VAC | ||||
Voltage range(battery mode) | ±1% | ||||
Frequency range (Normal mode) | 46Hz-54Hz or 56Hz-64Hz | ||||
Frequency range (battery mode) | 50Hz±0.1Hz or 60Hz±0.1Hz | ||||
Waveform Distortion | ≦3%THD(linear load),≦5%THD(non-linear load) | ||||
Power factor | 0.8 | ||||
Crest Factor | 3:01 | ||||
Transfer time | 0ms | ||||
Waveform | Pure Sine wave | ||||
EFFICIENCY | |||||
Normal Mode | 89% | 89% | 89% | 90% | |
BATTERY | |||||
Battery Type | Sealed lead acid maintenance free battery | ||||
Quantity(pieces) | 2 | 3 | 6 | 8 | |
Charging Current(MAX) | 1.0A | 6.0A | |||
DISPLAY | |||||
LCD | Load, battery capacity, normal mode, battery mode, bypass, failure |
||||
WARMING | |||||
Battery mode | Sounding every 4 seconds | ||||
Low battery | Sounding every 1 seconds | ||||
Overload | Sounding every second | ||||
Fault | Contentiously Sounding | ||||
PHYSICAL characteristic | |||||
Dimension,D×W×H (mm) | 410×438×88[2U] | 310×438×88[2U] | 410×438×88[2U] | ||
Net Weight(KGS) | 15.5 | 9 | 12 | 14.2 | |
WORK ENVIRONMENT | |||||
Humidity | 20~90% (Non-Condensing), 0~40℃ centigrade | ||||
Noise level | less than 50dB @ 1m | ||||
MAINTENANCE | |||||
Modbus RS-232/RS485 | Support Windows 2000/2003/XP/Vista/2008/7/8,Linux,Unix and MAC | ||||
Optional SNMP | Power management from SNMP manager and Web browser |
FAQ
Q 1. what's the payment terms?
A. We accept LC, T/T, PayPal, Western Union
Q 2. how's the delivery time ?
A. usually it will take about two weeks for production
Q 3. tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.
Q 4. Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q 5.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Q 6.We want to know month capacity.
A. It depends on which model.For example for relay type small capacity , month capacity can reach near 10000pcs and big capacity near 2000pcs.
Q 7.Where is your market?
A. Our products are popular in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East,Eastern Asia, Western Europe and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.
Q 8. what kind of certificate you have ?
A. Our company already achieve ISO9001, and for products, we have CE,TLC,ROHS.
