4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection
4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection
4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection
4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection
4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection
4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection
Specifications
Brand Name :
Dell
Model Number :
PA-30W
Certification :
ce fcc rohs
Place of Origin :
China
MOQ :
50pcs
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
10000pcs per month
Delivery Time :
5-8 work days
Packaging Details :
Regular package: each one with PE bag note:adapter only, without AC line
Color :
Black
Model :
90w laptop ac adapter
Warranty :
13 months
Condition :
Brand new original
Brand :
DELL/OEM
Usage :
DELL laptop
DC size :
4.8*1.7mm
Type :
Laptop AC Adapter
Output Type :
DC
Protection :
Short Circuit Protection, OLP, ocp, ovp, OTP
Material :
PC Fireproof Material
Product Name :
DELL 30W 19v 1.58a AC Adapter
Output :
19v 1.58a
Input :
AC 100V - 240V(50/60HZ)
AC Plug :
US UK AU,etc
Description

Dell Factory 30W 19V 1.58A 4.8*1.7mm Laptop AC Adapter

Product Description for this DELL 30W Laptop AC Adapter

1. Smart device surge protection for over voltage, short circuit protection.
2. Strong built for heavy duty and long usage performance.
3. CE,RoHS,FCC certified.

Brand DELL Tips 4.8*1.7mm
Usage for dell Color Black
size 85*35*27mm weight 135g
Output 19V 1.58A Type Desktop
Input Voltage

100-240V ac

Universal Input

 Power 30W
Certifications CE FCC ROHS
DC Connector

4.8*1.7mm
Instructions

If you don't know whether this machine can use this adapter, you can view your

original adapter's output parameters ( Output voltage, current ) whether

suitable, if the original adapter lost, or you can look at the electronic equipment

at the bottom of the parameters of the machine specifications
Protection

Over Loading Protection; Over Voltage Protection;

Temperature Protection; Short Circuit Protection.

Technical Specification:

Condition: 100% Brand New
Input: 100 to 240V AC,1.0-0.6A, 50 to 60Hz
Protection: Over-current, voltage and auto recovery
Output Protection: Over-load and short-circuit protection
AC Inlet: Plug-in type
Input Inrush Current (cold): 30A / 230V AC
Input Leakage Current: <0.5ma / 230V AC
Power Adjustment Rate (full load): ≤ 0.5%
Load Regulation: ≥ 1%
Output Stability: 0.5% typ.
Output Voltage Micro-Adjustment Range: ± 10%
Output Ripple (resistive load): 100mVp typ
Output Overload: 115% ~ 150%
Insulation Strength: Class A

Pictures for this DELL 30W Laptop AC Adapter

4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection

4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection4.8*1.7mm Dell Laptop AC Adapter 19V 1.58A 30W Short Circuit Protection

FAQ

1, What kind of company we are?

We are professional power supply manufacturer with high reputation in this field.

2, How we control the quality?

Aging test for 8 hours, after then we put them into the market.

3, Can we accept samples customized?

No problem for samples order, and welcome your testing before your big order.

4, OEM and ODM are available?

Yes, we accept customized products.

5, Will the delivery time be long for a big order?

No, we have two special parts in production line, one for samples orders, another for big orders, so we can control the delivery time as we promise in the contract.

6. What is our warranty service?

For all products we sell have 13 months warranty.
