Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
Specifications
Brand Name :
Zoomlion
Model Number :
QUY130
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-7 Days
Packaging Details :
Bulk
Product Name :
Used Zoomlion Crawler Crane
Condition: :
Used
Maximum Lifting Height: :
64 - 83m
Maximum Lifting Weight: :
> 130ton
Jib: :
3 Section
Specification :
9.55×6.50×3.20m
 production date: :
2013
Description

Used Zoomlion Crawler Crane Zoomlion QUY130 Second Hand Crawler Crane

Production Details:

Model NO.

QUY130

 Boom Type

Tower boom

Max. Rated Lifting Capacity

 130000 kg Max. Lifting Height of Jib 46.58m

Max. Gradeability

 30% Working hours 13500h

Transport Package

 Compliant with export packaging requirements Specification

9.55×6.5×3.2m

Trademark

 Zoomlion Origin China

Zoomlion QUY130 crawler crane, safe control system: two operation modes of work and installation are convenient and reliable; equipped with real-time display of levelness, off-machine stop action, emergency electrical control, lightning protection, automatic direction adjustment for driving, closed circuit Monitoring and other functions, complete security and monitoring systems.

Excellent operating performance: load sensing, limit load adjustment and electro-hydraulic proportional micro-speed control make each movement excellent in micro-movement and operate more smoothly;

In addition, the equipment has been in operation for 9 years, no big repair records, and the equipment is properly maintained. The main boom length is 64m, the Jib length is 19m, two hooks, 100 tons and 12 tons, no quick release, no overfitting, and the current performance is still very good, your professional choice.

Product Parameters:

Project Value Remarks
Max. lifting weight ×Width (t×m) 130×4.5
Max. Lifting Moment (t.m) 661.5 94.5(lifting weight)×7(width)
Self-weight when basic arm (t) 113.8
Boom length (m) 19～73
Fixed jib length (m) 13～31
Max. lifting capacity of fixed jib (t) 13
Fixed jib mounting angle ° 10,30
Main arm + fixed jib max. length (m) 55+31,58+25,61+19
Max. speed of single rope of reel Main winch (m/min) 105 The outermost layer of the roll
Vice winch (m/min) 93 The outermost layer of the roll
Luffing winch (m/min) 52 The outermost layer of the roll
Swing speed (r/min) 0～2.2
Driving speed (km/h) 0～1.3
Climbing ability % 30%
Ground specific pressure (MPa) 0.1
Overall dimensions L×W×H (m) 9.55×6.5×3.2 mast boom not included
Engine Rated power/speed (Kw/rpm) 209/2000
Maximum output torque/speed (N.m/rpm) 1356/1400
Emission standard U．S．EPA Tier Ⅲ
Track gauge × ground length × track shoe width (mm) 5600×6850×900

Used Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler CraneUsed Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler CraneUsed Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler CraneUsed Zoomlion Crawler Crane Zoomlion QUY130 130ton Second Hand Crawler Crane
