Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Zoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
Specifications
Brand Name :
Zoomlion
Model Number :
ZCC1300
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-7 Days
Packaging Details :
Bulk
Product Name :
Used Zoomlion Crawler Crane
Condition: :
Used
Maximum Lifting Height: :
13~99 M
Maximum Lifting Weight: :
130ton
Jib: :
2 Section
Specification :
11.5×3×3M
 production date: :
2014
Description

Used Zoomlion Crawler Crane Zoomlion ZCC1300 Second Hand Crawler Crane

Production Details:


Model NO.

ZCC1300

Boom TypeTower boom


Max. Rated Lifting Capacity

1300000 kgMax. Lifting Height of Jib76m


Max Gradeability

30%Working hours8000H


Transport Package

Compliant with export packaging requirementsSpecification

11.5×3×3M


Trademark

ZoomlionPlace of OriginChina


HS Code

 Supply Capacity1 Units Per Month

  • ZCC1300 crawler crane is a new generation of medium tonnage 4.0 products built by Zoomlion. It integrates advanced technologies such as structural optimization, intelligent manufacturing, intelligent control, and information interconnection.
  • The intelligent functions are convenient and practical, the safety control is perfect, the newly upgraded control room is comfortable and convenient, and the electro-hydraulic system is mature and reliable.
  • It is especially suitable for hoisting industries such as municipal construction, subway construction, bridge construction, steel structure installation, port loading and unloading goods, etc.


Product Parameters:

ItemValueRemarks
Main boomMax. lifting weight×width (t×m)130×5
Max. lifting moment (t.m)717.6
Main boom length (m)19～76
Fixed jibMax. lifting weight×width (t×m)24×14
Fixed jib length (m)13～31
Install jib main boom length (m)40～64
Max. length of main arm + fixed jib (m)61+31
64+25
Fixed jib installation angle (°)10°,30°
Winch speedMain lifting speed (m/min)117(6th floor)
Auxiliary lifting speed (m/min)110(5th floor)
Main luffing speed (m/min)56(6th floor)
Vehicle parametersRotation speed (r/min)0～2.2
Walking speed (km/h)0～1.3
Turntable counterweight weight (t)47
Body weight (t)10
Max. single piece shipping weight (t)33
Weight of the whole machine with basic boom (t)121.8without hook
With basic arm no-load average ground pressure (Mpa)0.1
Max. shipping size (m) (L×W×H)11.5×3×3
EngineModelQSL9-C280
Rated power/speed (kw/rpm)209/2000
Max. torque Nm/speed rpm1424/1500
Emission StandardsU．S．EPA Tier Ⅲ
Track gauge × track ground length × track shoe width (mm)5850×6850×900


Zoomlion ZCC1300 Second Hand Crawler Cranes 130 TonZoomlion ZCC1300 Second Hand Crawler Cranes 130 TonZoomlion ZCC1300 Second Hand Crawler Cranes 130 Ton
