STC80 Zoomlion Used Truck Cranes 80ton Second Hand Truck Cranes For Sale
STC80 Zoomlion Used Truck Cranes 80ton Second Hand Truck Cranes For Sale
STC80 Zoomlion Used Truck Cranes 80ton Second Hand Truck Cranes For Sale
STC80 Zoomlion Used Truck Cranes 80ton Second Hand Truck Cranes For Sale
Specifications
Brand Name :
Zoomlion
Model Number :
STC80
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-7 Days
Packaging Details :
Bulk
Status: :
Used
Max. Lifting Height: :
12.9 - 65m
Max. Lifting Weight: :
80ton
Axle No.: :
4
Jib boom: :
2 Section
Production date: :
2014
Description

Used Zoomlion Truck Crane Zoomlion STC80 Second Hand Truck Mobile Crane

Production Details:


Model No.

STC80

 Boom Type Telescopic


Max. Rated Lifting Capacity

 80000 kg Max. Lifting Height of Jib

50m


Max Gradeability

 44% Working Diameter 24m


Transport Package

 Complies with Min. export packaging requirements Specification

15290×2400×3210mm


Driving Mileage

 120000M Working hours 12000h


Trademark

 Zoomlion Place of Origin China


HS Code

 Supply Capacity

10 Units/ Month

1. High energy efficiency--new 80tons mobile truck crane

  1. 5 sections U-shaped main boom, with large cross-section, the full length of the boom is 50meters;
  2. Brand new 2.8meters wide chassis, heightened and widened rectangular section frame, enhanced torsional and bending resistance of hoisting load;
  3. Adopt high horsepower 12L engine, 10 speed gearbox with synchronizer, heavy duty axle;
  4. The max. grade is 44%, the fuel consumption/100 km is 44L.

2. Energy-saving and high efficiency hydraulic system

  1. Good brand oil pump, hoisting motor configuration, to meet the requirements of precision hoisting: the Min. stable speed of rotation is 0.1°/s, and the Min. stable speed of hoisting is 1.5meters per minute;
  2. Compared with the hydraulic control system, the electronic control system saves 15% of the overall energy saving when hoisting on the truck, and the heavy-load operation efficiency increases by 30%;

3. Comfortable, safe operating experience

  1. The 0-20° widened and tiltable control space makes working at heights more comfortable and safer;
  2. Remote-control operation Counterweight, mechanical structure mounting, do not need to unload for short-way transportation, reliable and safe;
  3. The boarding shed is simplified, the maintenance is easy, and use is more convenient.


Product Parameters:

Overall length of the whole machine 15290mm
Overall width of the whole machine 2800mm
Overall height of the whole machine 3880mm
Engine max. power 276/1900Kw/rpm
Engine max. output torque 1800/1000-1400N.m/rpm
Top speed 80Km/h
Min. turning radius 12m
Approach angle ≥10°
Departure angle ≥14°
Max. gradeability 44%
Oil consumption per 100 km ≤44L
Max. rated lifting capacity 80t
Turntable tail turning radius 4.385m
max. load moment - Basic Arm 3293kN.m
max. load moment - Longest Main Boom 1803kN.m
Outrigger span (horizontal × vertical) 8×6.43m
Boom Length - Basic Boom 12.96m
Boom Length - Longest Main Boom 50m
Boom length - longest main boom + jib 67.5m
Main hoist single rope max. speed (no load) 130m/min
Max. speed of the auxiliary hoist single rope (no load) 130m/min
Boom full extension/retraction time 140s/160s
Boom full up/down time 65s/90s
Swing speed 0 ～ 1.8r/min
The total mass of the whole machine 50000
Axle load - one and two axle loads 24000kg
Axle load - three and four axle loads 26000kg

STC80 Zoomlion Used Truck Cranes 80ton Second Hand Truck Cranes For SaleSTC80 Zoomlion Used Truck Cranes 80ton Second Hand Truck Cranes For Sale
