XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale
XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale
XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale
XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale
Specifications
Brand Name :
XCMG
Model Number :
XCT75
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10PCS/M
Delivery Time :
5-7 Days
Packaging Details :
Bulk
Condition: :
Used
Maximum Lifting Height: :
12.4- 74m
Maximum Lifting Weight: :
75ton
Axle Number: :
4
Jib: :
2 Section
 production date: :
2018
Description

Used Truck Crane XCMG XCT75 Second Hand Truck Mobile Crane

Production Details:

Model No.

XCT75

 Boom Type Telescopic

Max. Rated Lifting Capacity

 75000 kg Max. Lifting Height of Jib 48m

Max Gradeability

 45% Working Diameter 24m

Transport Package

 Complies with Min. export packaging requirements Specification

14700×2750×3910mm

Driving Mileage

 400000M Working hours 3200h

Trademark

 XCMG Place of Origin China

HS Code

 Supply Capacity 10 Units/ Month

XCMG XCT 75-ton truck crane, K-type outrigger, compact structure, leading performance, safe and reliable, economical and environmentally friendly, is a high-quality model tailored for users.

  • The overall lifting performance of the 75-80-ton products leads the industry, and the lifting performance of the whole machine is more than 20% higher than that of the products of the same tonnage in the industry;
  • Low-speed high-torque power system, strong power, strong off-road capability and low fuel consumption. Fuel consumption is reduced by 12%, and gradeability is improved by 15%;
  • New energy-saving hydraulic system, dual-pump split and confluence, fast speed and good compound action. The average fuel consumption under comprehensive working conditions is reduced by 8%, and the ride comfort and fretting performance are improved by 15%;
  • The new human-computer interaction system makes driving more comfortable;
  • A new generation of appearance, humanized design, user operation is more comfortable and convenient;

Product Parameters:

Parameter item XCT75
Dimensions *
Overall length of the whole machine (mm) 14700
Overall width of the whole machine (mm) 2750
Overall height of the whole machine (mm) 3910
Wheelbase(mm) 1470+3950+1350
Tire distance(mm) 2316/2063
Weight parameter *
Total mass in driving state (kg) 46000
Axle load(kg) 10000×2+13000×2
Dynamic parameters *
Engine model MC11.36-40SC10E360Q4
Engine rated power (kw/(r/min)) 268/1900 265/1900
Engine rated torque (N.m/(r/min)) 1800/1000-14001700/1300
Traveling parameters *
Traveling *
Max. travel speed (km/h) 90
Min. stable driving speed (km/h) 2.5～3
Turning *
Min. turning diameter (m) 24
Arm head Min. turning diameter (m) 28.8
Max. grade(%) 45
Min. ground clearance (mm) 305
Approach angle (°) 16
Departure angle (°) 13.5
Braking distance (m) ≤10
Fuel consumption per 100 kilometers (L) 40
Main performance parameters *
Max. rated total lifting weight (t) 75
Min. rated amplitude (m) 3
The Max. lifting moment of the basic arm (kN m) 3175
Turntable tail turning radius (mm) 4545
Outrigger *
Longitudinal (m) 8.45
Horizontal (m) 7.9(5.6)
Max. lift height *
Basic arm (m) 12.7
The longest main boom (m) 48
The longest main boom + jib (m) 65
The longest main boom + jib + extension 74
Boom length *
Basic arm (m) 12.4
Longest main boom (m) 48
Longest main boom + jib 65.5
The longest main boom + jib + extension section (m) 74.5
Working speed *
Max. rotation speed (r/min) 2
Lifting speed *
Main hoisting mechanism 145
Auxiliary lifting mechanism 90
Boom extension time *
Full extension(s) 110
Full shrink -
Amplitude time *
Full lift (s) 55
Full arm drop(s) -
Outrigger retraction--horizontal *
Simultaneously put -- horizontal (s) 50
At the same time closing -- horizontal (s) 40
Outrigger retraction-vertical *
Simultaneously put(s) 50
Simultaneous receipt (s) 45
XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For SaleXCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale
