Used Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile Crane
Used Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile Crane
Used Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile Crane
Used Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile Crane
Used Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile Crane
Used Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile Crane
Specifications
Brand Name :
Zoomlion
Model Number :
QY150V633
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-7 Days
Packaging Details :
Bulk
Condition: :
Used
Maximum Lifting Height: :
14 - 86m
Maximum Lifting Weight: :
150ton
Axle Number: :
5
Jib: :
2 Section
 production date: :
2012
Description

Used Zoomlion Truck Crane Zoomlion QY150V633 Second Hand Truck Mobile Crane

Production Details:


Model No.

QY150V633

 Boom Type Telescopic


Max. Rated Lifting Capacity

 150000 kg Max. Lifting Height of Jib 60m


Max Gradeability

 40% Working Diameter 24m


Transport Package

 Complies with Min. export packaging requirements Specification

14990×3000×3950MM


Driving Mileage

 11000KM Working hours 5000h


Trademark

 Zoomlion Place of Origin China


HS Code

 Supply Capacity

10 Units/ Month

  • Zoomlion QY150V633 truck crane is a high-performance and high-reliability crane designed and developed by our company in order to meet the market demand, using the technology of designing and manufacturing mobile cranes for many years and combining with international advanced technology.
  • This product is a high-tech product with a high concentration of electromechanical hydraulic systems. It will be active in various fields of my country's economic construction with its excellent handling performance, excellent fretting performance, huge lifting capacity and extraordinary lifting height.
  • This product is suitable for lifting operations and installation projects in chemical, mining, oil fields, ports, construction sites and other places. This product is not suitable for areas with strong electromagnetic waves.
  • This product is a full-slewing, telescopic boom type, electro-hydraulic proportional control truck crane. It adopts the company's self-made full-drive six-axle special chassis, with wide field of vision, luxurious and comfortable decoration, three-axle drive and four-axle steering.


Product Parameters:

Item Value Remarks
Working performance Max. rated total lifting weight (kg) 150000
Max. load moment of the basic boom (kN.m) 5292 6m range
Max. load moment of the longest main boom (kN.m) 2264 22m range
Max. lifting height of the basic boom (m) 13.5
Max. lifting height of main boom (m) 60

The deformation of the boom is not considered, and the value in brackets is the value of the extension arm
Max. lifting height of jib (m) 78.4 / (86)
Working speeds Max. speed of single rope (main winch) (m/min) 110 At fifth layer
Max. speed of single rope (auxiliary winch) (m/min) 75 At third layer
Boom derricking up time (s) 78
Boom telescoping out time (min) 12
Max. rotation speed (r/min) 1.5
Driving parameters Max. driving speed (km/h) 72
Max. gradeability (%) 40
Min. turning diameter (m) ≤24
Min. ground clearance (mm) 280
Exhaust Pollutant Emission Value and Smoke Level Limit Comply with the standard

GB3847-2005

GB17691-2005(Euro Ⅲ)
Fuel consumption per 100 kilometers (L) 85
Weight parameters Deadweight in traveling condition(kg) 54900
Complete vehicle kerb mass (kg) 54705
Ⅰ, Ⅱ, Ⅲ axle load (kg) 8700/8700/8700/
Ⅳ, Ⅴ, Ⅵ axle load (kg) 20800(Dual axis)/8000
Dimensions Dimensions (L×W×H) (mm) 14990×3000×3950
Longitudinal distance of outriggers (m) 7.04
Outrigger lateral distance (m)

8.5(Full extension),

6.5(Half extension)
Main arm length (m) 13~59
Main boom elevation angle (°) -1.5～82
Jib length (m) 11 ,18.6
Jib + extension arm (m) 26.6
Offset (°) 0 ,15, 30
Used Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile CraneUsed Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile CraneUsed Zoomlion Used Truck Cranes QY150V633 Second Hand Truck Mobile Crane
