US-16-150W 18 Gbps Poe 16 Ports Gigabit Switch
US-16-150W 18 Gbps Poe 16 Ports Gigabit Switch
US-16-150W 18 Gbps Poe 16 Ports Gigabit Switch
US-16-150W 18 Gbps Poe 16 Ports Gigabit Switch
US-16-150W 18 Gbps Poe 16 Ports Gigabit Switch
US-16-150W 18 Gbps Poe 16 Ports Gigabit Switch
Specifications
Brand Name :
Unifi
Model Number :
US-16-150W
Place of Origin :
USA
MOQ :
1 Unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 pcs per week
Delivery Time :
3~5 working days
Packaging Details :
Original packing
Brand :
Unifi
Product name :
US-16-150W
Type :
Unifi Switch 16 150W
POWER :
150W
Gigabit RJ45 Ports :
16
SFP Ports :
2
Throughput :
18 Gbps
Description

Ubiquiti UniFi Switch US-16-150W Gigabit 16 Ports POE+ Switch 24/48V 150W

The UniFi Switch delivers robust performance over its 18 independent switching ports. Two SFP ports offer optical connectivity, and 16 Gigabit Ethernet ports offer 802.3af/at PoE+ or 24V passive PoE sharing a total of 150W PoE.

16 Gigabit RJ45 ports offer convenient different power output options: auto-sensing IEEE 802.3af/at PoE/PoE+ and 24V passive PoE, and two SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps.

• (16) Gigabit RJ45 Ports
• (2) SFP Ports
• (1) Serial Console Port (Reserved for Future Use)
• Non-Blocking Throughput: 18 Gbps
• Switching Capacity: 36 Gbps
• Forwarding Rate: 26.78 Mpps
• Maximum Power Consumption: 150W
• Supports POE+ IEEE 802.3at/af and 24V Passive PoE
• Rack-Mountable or Wall-Mountable with Rack-Mount Brackets (Included)

Specification:

Dimensions: 443 x 43 x 221 mm (17.44 x 1.69 x 8.70")
Weight Rack-Mount Brackets Excluded: 2.80 kg (6.17 lb)
Weight Rack-Mount Brackets Included: 2.89 kg (6.37 lb)
Networking Interfaces: (16) 10/100/1000 Mbps RJ45 Ethernet Ports, (2) 1 Gbps SFP Ethernet Ports
Management Interface: Ethernet In-Band
Total Non-Blocking Throughput: 18 Gbps
Switching Capacity: 36 Gbps
Forwarding Rate: 26.78 Mpps
Power Method: 100-240VAC/50-60 Hz, Universal Input
Power Supply: AC/DC, Internal, 150W DC
Max. Power Consumption Including PoE Output: 150W
Max. Power Consumption Excluding PoE Output: 28W
LEDs Per Port, RJ45 Data Ports: PoE, Speed/Link/Activity
LEDs Per Port, SFP Data Ports: Speed/Link/Activity
Sound Level Fan Level 0: 34 dBa
Sound Level Fan Level: 1, 2, 3: 37 dBa
ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
Shock and Vibration: ETSI300-019-1.4 Standard
Operating Temperature: -5 to 40° C (23 to 104° F)
Operating Humidity: 5 to 95% Noncondensing
item
value
Products Status
Stock
Ports
16
Transmission Rate
10/100/1000Mbps
Function
POE
Certification
FCC, ce
Brand Name
Ubiquiti
Model Number
US-16-150W
US-16-150W 18 Gbps Poe 16 Ports Gigabit SwitchUS-16-150W 18 Gbps Poe 16 Ports Gigabit SwitchUS-16-150W 18 Gbps Poe 16 Ports Gigabit SwitchUS-16-150W 18 Gbps Poe 16 Ports Gigabit Switch
US-16-150W 18 Gbps Poe 16 Ports Gigabit Switch
