S5730-68C-PWR-SI-AC S5730 48 Port Layer 3 POE Ethernet Switch
S5730-68C-PWR-SI-AC S5730 48 Port Layer 3 POE Ethernet Switch
S5730-68C-PWR-SI-AC S5730 48 Port Layer 3 POE Ethernet Switch
S5730-68C-PWR-SI-AC S5730 48 Port Layer 3 POE Ethernet Switch
S5730-68C-PWR-SI-AC S5730 48 Port Layer 3 POE Ethernet Switch
S5730-68C-PWR-SI-AC S5730 48 Port Layer 3 POE Ethernet Switch
S5730-68C-PWR-SI-AC S5730 48 Port Layer 3 POE Ethernet Switch
S5730-68C-PWR-SI-AC S5730 48 Port Layer 3 POE Ethernet Switch
Specifications
Brand Name :
huawei
Model Number :
S5730-68C-PWR-SI-AC
Place of Origin :
china
MOQ :
1 Unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 pcs per week
Delivery Time :
3~5 working days
Packaging Details :
Original packing
Brand :
huawei
Product name :
S5730-68C-PWR-SI-AC
Device type :
Huawei POE Switch
Product type :
Huawei S5730 Switch
Ports :
48 x 10/100/1,000 Base-T ports
uplink ports :
4x 10 GE SFP+
Switching Capacity :
680 Gbit/s
Forward rate :
240 Mpps
Description

Huawei S5730-68C-PWR-SI-AC S5730 48 Port Gigabit Layer 3 POE Ethernet Switch​

S5730-SI Series Switches

The S5730-SI series switches (S5730-SI for short) are next-generation standard gigabit Layer 3 Ethernet switches. They can be used as an access or aggregation switch on a campus network or as an access switch in a data center.

The S5730-SI series switches provide flexible full gigabit access and cost-effective fixed GE/10 GE uplink ports. Meanwhile, the S5730-SI can provide 4 x 40 GE uplink ports with an interface card.

Product model S5730-48C-SI-AC S5730-48C-PWR-SI-AC S5730-68C-SI-AC S5730-68C-PWR-SI-AC
S5730-68C-PWR-SI
Switching Capacity 680 Gbit/s 680 Gbit/s 680 Gbit/s 680 Gbit/s
Forwarding Performance 240 Mpps 240 Mpps 240 Mpps 240 Mpps
Fixed Ports 24 x 10/100/1,000 Base-T, 8 x 10 Gigabit SFP+ 24 x 10/100/1,000 Base-T, 8 x 10 Gigabit SFP+ 48 x 10/100/1,000 Base-T, 4 x 10 Gigabit SFP+ 48 x 10/100/1,000 Base-T, 4 x 10 Gigabit SFP+
Extended Slots One extended slot that supports an interface card: 4 x 40 GE QSFP+ interface card
MAC Address Table 32K
MAC address learning and aging
Static, dynamic, and blackhole MAC address entries
Packet filtering based on source MAC addresses
VLAN Features 4,094 VLANs
Guest VLAN, Voice VLAN
GVRP
MUX VLAN
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
1:1 and N:1 VLAN mapping
IP Routing Static route, RIPv1/v2, RIPng, OSPF, OSPFv3, ECMP, IS-IS, IS-ISv6, BGP, BGP4+, VRRP, and VRRP6
Interoperability VLAN-Based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST)
Link-type Negotiation Protocol (LNP) (similar to DTP)
VLAN Central Management Protocol (VCMP) (similar to VTP)
