S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
Specifications
Brand Name :
huawei
Model Number :
S5720-14X-PWH-SI-AC
Place of Origin :
china
MOQ :
1 Unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 pcs per week
Delivery Time :
3~5 working days
Packaging Details :
Original packing
Brand :
huawei
Product name :
S5720-14X-PWH-SI-AC
Device type :
Huawei 46 ports Gigabit Switch
Product type :
Huawei S5720 Switch
Ports :
8 PoE+ 10/100/1000BASE-T ports, 4 PoE++ 100M/1000M/2.5GE BASE-T ports (MultiGE port)
uplink ports :
2x 10 Gig SFP+
poe power :
370W
Switching Capacity :
336 Gbit/s
Description

Huawei S5720-14X-PWH-SI-AC 8 PoE+ Gigabit Port 2x 10GE SFP+ Ports Layer 3 Switch​

S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch

1.Eight PoE+ 10/100/1000BASE-T ports
2.Four PoE++ 100M/1000M/2.5GE BASE-T ports (MultiGE port)
3.Two 10GE SFP+ ports
Applicable modules and cables:
* GE optical module
* GE-CWDM optical module
* GE-DWDM optical module
* GE copper module (only 1000 Mbit/s supported)
* 10GE SFP+ optical module (OSXD22N00 not supported)
* 10GE-CWDM optical module
* 10GE-DWDM optical module
* 1 m, 3 m, 5 m, and 10 m SFP+ high-speed copper cables
* 3 m and 10 m AOC cables
* 0.5 m and 1.5 m SFP+ dedicated stack copper cables (used for zero-configuration stacking, supported in V200R011C10 and later versions)
4.One console port
5.One ETH management port
6.One USB port
7.Ground screw
8.AC socket

Item

Description
Memory (RAM) 1 GB
Flash 512 MB in total. To view the available flash memory size, run the display version command.
Power supply surge protection ±6 kV in differential mode, ±6 kV in common mode
Dimensions (H x W x D) 43.6 mm x 442.0 mm x 310.0 mm (1.72 in. x 17.4 in. x 12.2 in.)
Weight (with packaging) 5.9 kg (13.01 lb)
Stack ports

First eight GE electrical ports

10GE SFP+ ports (V200R010C00 and later versions)
RTC Supported
RPS Not supported
PoE Supported
Rated voltage range 100 V AC to 240 V AC, 50/60 Hz
Maximum voltage range 90 V AC to 264 V AC, 47 Hz to 63 Hz
Maximum power consumption (100% throughput, full speed of fans)
  • Not providing the PoE function: 52 W
  • 100% PoE loads: 422 W (system power consumption: 52 W, PoE: 370 W)
Typical power consumption (30% of traffic load)
  • Tested according to ATIS standard
  • EEE enabled
  • No PoE power consumption
 44.94 W

S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network SwitchS5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network SwitchS5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch

S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network SwitchS5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network SwitchS5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network SwitchS5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch

S5720-14X-PWH-SI-AC 2x 10GE SFP+ Cisco Poe Network Switch
