DOM Transceiver Used Cisco Modules SFP-10G-BX80U-I SFP-10G-BX80D-I 1490/1550nm 10G SFP+ 80km
DOM Transceiver Used Cisco Modules SFP-10G-BX80U-I SFP-10G-BX80D-I 1490/1550nm 10G SFP+ 80km
DOM Transceiver Used Cisco Modules SFP-10G-BX80U-I SFP-10G-BX80D-I 1490/1550nm 10G SFP+ 80km
DOM Transceiver Used Cisco Modules SFP-10G-BX80U-I SFP-10G-BX80D-I 1490/1550nm 10G SFP+ 80km
Specifications
Brand Name :
BO-NET
Model Number :
SFP-10G-BX80D-I
Place of Origin :
china
MOQ :
1pcs
Payment Terms :
T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :
200pcs per week
Delivery Time :
2day
Packaging Details :
carton
Product name :
Cisco Optical Transceiver
Brand :
BO-NET
Product Name :
SFP-10G-BX80D-I
Type :
Fiber Module
Distance :
80km
Device type :
SFP Transceiver Module
Product Name 1 :
SFP-10G-BX80U-I
Wavelength :
1490nm/1550nm
Description

Cisco SFP-10G-BX80U-I SFP-10G-BX80D-I 1490nmTX/1550nmRX 10G SFP+ 80km DOM Transceiver Fiber Module

SFP-10G-BX80D-I and SFP-10G-BX80U-I (for 80Km single-fiber bidirectional applications)

The SFP-10G-BX80D-I and SFP-10G-BX80U-I SFPs operate on a single strand of standard SMF.

A SFP-10G-BX80D-I device is always connected to a SFP-10G-BX80U-I device with a single strand of standard SMF with an operating transmission range up to 80 km.

The communication over a single strand of fiber is achieved by separating the transmission wavelength of the two devices. SFP-10G-BX80D-I transmits a 1550-nm channel and receives a 1490-nm signal. The SFP-10G-BX80U-I transmits at a 1490-nm wavelength and receives a 1550-nm signal.

The SFP-10G-BX80D-I and SFP-10G-BX80U-I SFPs support Digital Optical Monitoring (DOM) functions according to the industry-standard SFF-8472 Multisource Agreement (MSA). This feature gives the end user the ability to monitor real-time parameters of the SFP, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.

SFP+ Wavelength (nm) Cable Type Core Size (Microns) Cable Distance
SFP-10G-BX80D-I 1550 SMF G.652 80km
SFP-10G-BX80U-I 1490 SMF G.652 80km

Description Product Number
10GBASE-BX10-D Bidirectional for 10km SFP-10G-BXD-I
10GBASE-BX10-U Bidirectional for 10km SFP-10G-BXU-I
10GBASE-BX40-D Bidirectional for 40km SFP-10G-BX40D-I
10GBASE-BX40-U Bidirectional for 40km SFP-10G-BX40U-I
10GBASE-BX60-D Bidirectional for 60km SFP-10G-BX60D-I
10GBASE-BX60-U Bidirectional for 60km SFP-10G-BX60U-I
10GBASE-BX80-D Bidirectional for 80km SFP-10G-BX80D-I
10GBASE-BX80-U Bidirectional for 80km SFP-10G-BX80U-I
