Model | AirEngine 5760-51 |
Dimensions (Diameter x Height) | 220 mm x 50 mm |
Power Input | DC: 48 V ± 10% |
PoE power supply: in compliance with IEEE 802.3bt |
Maximum Number of Users | ≤ 1024 (dual-radio mode) |
≤ 1152 (triple-radio mode) |
Note: The actual number of users varies according to the environment. |
Port | 1 x 5 GE and 1 x GE electrical |
IoT | Built-in IoT slots |
Operating Temperature | –10°C to 50°C |
Antenna Type | Built-in Smart Antennas |
MIMO: Spatial Streams | Basic capability: |
2.4 GHz: 2x2:2; 5 GHz: 4x4:4 |
2.4 GHz: 2x2:2; 5 GHz-0: 2x2:2; 5 GHz-1: 2x2:2 |
Capability upgrade via RTU license: |
2.4 GHz: 4x4:4; 5 GHz: 4x4:4 |
2.4 GHz: 2x2:2; 5 GHz-0: 2x2:2; 5 GHz-1: 4x4:4 |
Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2/ax |
Maximum Data Rate | Basic capability: up to 5.37 Gbit/s |
RTU license upgrade: up to 5.95 Gbit/s |
